Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
.An internal Compact Flash memory card can be used to expand the project memory. Compact Flash cards of type I and II are supported by the operator panels. Recommended Compact Flash memory cards are SiliconSystems SiliconDrive, SanDisk Industrial Grade and Cactus 203-, 302-, 303-series. Installation Perform the following steps to install an internal Compact Flash card in the operator panel: 1. Turn off the power to the panel. 2. Remove the back cover on the operator panel, using a torx screwdriver (T10*50). ‘ When using an internal Compact Flash memory card, no external Compact Flash memory card can be used. An external USB Flash drive can be used for the same functions as an external Compact Flash card. Observe precautions for handling electrostatic sensitive devices. 1 4 Torx Screws Internal Compact Flash Memory Card Section 3 Installation 20 3BSE043449R501 3. Flip the back cover; the CPU board is mounted inside the back cover. 4. Insert the Compact Flash memory card in its slot on the CPU board. 5. Re-attach the back cover to the operator panel. 6. Turn on the power to the operator panel. 7. When the operator panel starts up, you will be asked if you like to move the files to the internal card; select YES to this question. Settings in Panel Builder 800 The size of the internal memory card must be entered in the configuration tool for the operator panel. 1. Select Setup/Terminal Options. 2. Enter the size of the internal memory card under Memory card settings/Internal. Caution - If the CPU card and power card is disconnected from each other for a longer period of time, the panel may not boot when it is reassembled again. To remedy this problem, a hardware reset needs to be performed by setting the mode switch no. 4. Internal Compact Flash memory card slot Section 3 Installation Expansion Module for Profibus DP 3BSE043449R501 21 3. Click OK to close the dialog. Expansion Module for Profibus DP An expansion module can be used for connection via Profibus DP. Observe precautions for handling electrostatic sensitive devices. Expansion Module for Profibus DP Section 3 Installation 22 3BSE043449R501 Space Requirements Installation 1. Unpack and check the delivery. If damage is found, notify the supplier. 2. Disconnect the operator panel from the power supply.
>>
