Vertical Knee-Type Milling Machine (X5032)

Product Description

VERTICAL MILLING MACHINE FEATURES:
Model X5032 Vertical Knee-type Milling Machine, has extra travel in longitudinal, operating control adopts a cantilever panel. It is suit for milling flat, inclined face, angular surface, slots by employing disc cutters, angular cutters. When mounted with the index, the machine will be able to perform milling operations in gears, cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ± 45° . Spindle quill can be moved in vertical. The longitudinal, cross and vertical movements of the table can both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.
SPECIFICATIONS:

SPECIFICATION	UNIT	X5032	X5032B
Table size	mm	320X1325	320X1600
T-slots (NO./Width /Pitch)		3/18/70	3/18/70
Longitudinal travel (manual/auto)	mm	700/680	900/880
Cross travel (manual/auto)	mm	255/240	255/240
Vertical travel (manual/auto)	mm	350/330	350/330
Rapid feed speed	mm/min	2300/1540/770	2300/1540/770
Spindle bore	mm	29	29
Spindle taper		7:24 ISO50	7:24 ISO50
Spindle speed range	r/min	30~1500	30~1500
Spindle speed step	steps	18	18
Spindle travel	mm	70	70
Max.swivel angle of vertical milling head		±45°	±45°
Distance between spindle nose and table surface	mm	60-410	60-410
Distance between spindle axis and column guide way	mm	350	350
Feed motor power	kw	2.2	2.2
Main motor Power	kw	7.5	7.5
Overall dimensions(L×W×H)	mm	2294×1770 ×1904	2294×1770 ×1904
Net weight	kg	2900/3200	2900/3200

Contact Us:

Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.

---
