FFKM Perfluoro Elastomerrubber Halopolymer 1000p Solvay Kalrez High Temperature Resistance

Product Description

Company Profile
Sichuan Hongxin FFKM Technology Co., Ltd., a subsidiary of Sichuan Dowhon Group, specializes in R&D of FFKM compounds and FFKM O rings. At present, We have gained "Sichuan Gazelle Enterprise, National High-tech Enterprise, Sichuan Industrial Design Center, Technologically Advanced Little Giant Enterprise, Sichuan Enterprise Technology Center, Sichuan Most Influential Enterprise,Member of the Council of China Fluorosilicon Organic Materials Industry Association ", etc. We currently have 65 patents, participated in the formulation of 4 national standards, and 15 invention patents are under application. Meanwhile, we have been establishing a long-term and close cooperation with Sichuan University, Wuhan University, Qingdao University of Science and Technology, and South China University of Technology.
Keeping up with the pace times, HONSEAL FFKM O-rings emerged, and are widely used in pharmaceutical industry, aerospace, semiconductor, and defence as well as other industries.
The company's 10,000 level clarification production workshop specializes in the R&D and production of FFKM compounds and FFKM o rings, providing engineers with high-performance sealing components which are suitable for various static and dynamic applications.
Our FFKM gum comes from Russia. Being the exclusive agent in China, we have a more competitive price. Combined with unique material formula designation, we specialize in the production of high-quality FFKM compounds. Besides, we can customize FFKM o rings with different requires such as sizes, colors, etc according to customers.

Product Description

Fluorinated Content	72%
Specific Gravity	2 04
Physical form	Slab
Color	Black
Mooney Viscosity ML 1+ 10@ 121ºC	38
Heat resistance ( Long term) ºC	235

Instruction
It is designed products for cleaning and chemical etching
process of semiconductor industry and products for wet
electronic chemicals by compression molding
Features of 6061B1 are:
Excellent chemical resistance
Low compression set
Excellent hot resistance
Packing information
Honseal-6061B1 is packed with PE film in carton. The
weight is 0.5kg net per carton.
Safety and handling
Store in well ventilated place
Smoking is forbidden strictly in working areas
Avoid eye contact
Wash thoroughly any contacted skin and clothing Product Parameters
Typical properties of Vulcanizate
Compound PHR
FFKM POLYMER 100
FILLERS 20
101LX45 2.5
Taic (70%) 2.5
Rheological Properties
Gotech GT-M3000A 170ºC@ 10min Arc 0.5
ML, lb-In

MH, lb-In	25.72
Ts2, min	1'10''
T10, min	1'15''
T50, min	1'38''
T90 m n	3'10''

Physical Properties (ASTM D-412)
Press Cure 170ºC@ 10min, Post Cure:230ºC@ 16 hour
Hardness ,Shore A 60
Elongation at Break, % 180
Tensile ,MPa 16.4
Compression set % ASTM D395, method B(O-ring)
200C@70h , 18
Detailed Description & Usage:
FFKM stands for Fluorinated Fluorocarbon Rubber. It is a type of synthetic rubber that contains fluorinated atoms in its chemical structure.
Due to the presence of fluorinated, FFKM has exceptional chemical and heat resistance properties. It can withstand temperatures from -25°C to 200°C and has resistance to over 300 chemical agents that can degrade other elastomers.
Common chemical agents that FFKM is resistant to include hydrocarbon fuels, engine oils, hydraulic fluids, and refrigerants. It is often used in sealing applications where conventional rubber seals would fail, such as in pumps, valves, and gaskets in the oil & gas, chemical, and semiconductor industries.
FFKM maintains its flexibility even at very low and very high operating temperatures, allowing it to provide effective seals where other materials cannot. It has excellent compression set resistance, meaning it does not permanently deform when compressed for long periods. This allows seals and gaskets made from FFKM to maintain tight tolerances over the lifetime of equipment use. Detailed Photos

Packaging & Shipping

The Advantages of FFKM:
Excellent chemical resistance - FFKM contains fluorinated atoms that give it outstanding resistance to a wide range of chemicals like solvents, acids, bases, fuels and industrial fluids. This makes it very tolerant of harsh chemical environments.
High temperature performance - Due to the carbon-fluorinated bond strength, FFKM maintains its properties even at extreme high temperatures up to 200°C/392°F continuously. Some grades can handle short-term spikes up to 260°C/500°F. This far exceeds most other elastomers.
Low permeability - The tightly bound carbon-fluoriated structure makes FFKM extremely impermeable. Very few chemicals can penetrate it, rendering it suitable for applications involving gas or liquid containment and transmission.
Superior compression set resistance - When compressed for long periods, FFKM does not experience excessive deformation like other rubbers. It maintains tight seals over time without experiencing creep. This keeps equipment running efficiently. Low friction & wear properties - The slippery fluorinated surface results in low friction against mating parts.
Combined with good abrasion resistance, this reduces wear of dynamic seals and allows machinery to operate smoothly. Wide service temperature range - FFKM can handle applications from cryogenic -25°C/-13°F up to high temperatures without becoming brittle or breaking down. Its flexibility spans a greater working temperature window.
Weathering resistance - Exposure to sunlight, ozone gases etc has minimal effect on FFKM as the carbon-fluorinated bonds are extremely stable. It maintains properties for decades in outdoor equipment. Biocompatibility - Being highly inert, FFKM poses very little risk of reaction when used in applications involving food contact or medical devices. Certifications
ISO9001, ISO14001, ISO16949
Currently has 65 patents, 15 invention patents are under application, participated in the formulation of 4 National Standards.
FAQ

1, What's your MOQ? BY air MOQ is 20-25KG, by sea MOQ is 100KG. 2, What's your delivery time? For stock goods, we can arrange delivery within 3 working days, otherwise delivery time is around 7-14 working days. 3, What's your package? Usually goods are packaged with PE film in carton. The weight is 20-25kg net per carton. 500kgs/625kgs/700kgs in a pallet. 4, How can we select the exactly grade which suit for our usage? Please contact our sales, we'll recommend suitable grade according to your typical physical properties and other related information.

---
