| Glove mould size | 36.5×39cm |
| Glove Making Speed | 50-220Pcs/Min/Layer, total 440pcs/min |
| Film roll unwinding device | with mechanical shaft Tension Controller: 2.5KG magnetic barker with manual controller |
| Unwinding motor | Unwinding motor: 0.55KW, with 1.1KW inverter Controlling: main computer controlling. |
| Main driver | Structure: crank rocker push-pull structure Drive: A.C motor with inverter controlled, 1.5 KW, 6 grade Controlling: main computer controlling. |
| Front Traction motor | Structure: Friction type, Drive: Step motor Transmission: M-type synchronous belt wheel drive, Control form: step motor driver Detection method: photocell combined with proximity switch |
| Glove mould | Raw material: Cast copper Heating: heating pipe, with temperature controller, control temperature automatically. |
| Cutting knife | Width: 380mm Material: White Steel Alloy Drive mode: main motor connecting rod drive |
| Electric Cabinet | Main Computer: Touch screen microcomputer- Contactor, swift |
| Automatic waste edge tearing device | Waste edge tear model: tearing by batches, and delivery out by batches Controlling: PLC and pneumatic cylinder |
| Other | Tracking photocell: 1 set Static Eliminator: dry type, elimination bar * 2, elimination device * 1 Conveyor belt: 1 set |
| Weight | 1300KG |
| Over Size (L×W×H) | 2600×1000×1400mm |
