US$105.00
100-2,999 Pieces
US$79.00
3,000-9,999 Pieces
Basic Info.
Battery Capacity
3.8V/6600mAh
Hard Disk Capacity
64GB/128GB
Network Mode
WiFi, 3G, 4G, 4G
Built-in Bluetooth
Built-in Bluetooth
Built-in Microphone
Built-in Microphone
Fingerprint
Without Fingerprint
Screen Type
Capacitive Screen
Rear Camera Pixel
2/5/8MP
Front Camera Pixel
5/8/13MP
Display
10.36′′ IPS Incell 2000X1200
Network
802.11AC/a/B/G/N 2.4G+5g, Bt5.0, LTE
I/O
Type-C*1, USB Docking*1
Application
Education, Business, Entertainment...
Others
Custom on CPU, RAM/ROM, Display, Camera, etc.
Transport Package
Color Box: 1unit/Box
Specification
248.3x158.5x7.5mm
Production Capacity
200000 Pieces Per Month
Product Description
L1036IS-10.36''
It's an ultra-thin and economical model. In terms of operation experience, visual experience, wireless signal and other aspects, it has excellent and stable performance.
Features
1, 2000x1200 IPS incell screen
2, 4 box speakers(Optional), high quality stereo sound
3, Dual SIM slot
4, Magnalium+Plastic housing, lighter weight
5, Reserved docking design for keyboard or charging base, etc.
PHYSICAL PROPERTY
|
Type
| Item
| Description
|
WHOLE SET
| Shell
| Semi-metal
|
LCD protector
| Anti-scratch glass
|
Dimension(estimated)
| 248.3x158.5x7.5mm
|
HARDWARE
|
Type
| Item
| Description
|
OS
| Version
| Andriod 12 or Lower
|
PROCESSOR
| CPU
| T618(Octa core, 2.0GHz) T610(Octa core, 1.8GHz)
|
MEMORY
| RAM
| 4GB/6GB/8GB
|
ROM
| 64GB/128GB
|
DISPLAY
| Type
| IPS Incell
|
Size
| 10.36inch
|
Resolution
| 2000x1200
|
BATTERY
| Type
| Lithium-ion polymer battery
|
Capacity
| 3.8V/6000mAh(6600mAh max)
|
CAMERA
| Front pixels
| 2/5MP
|
Rear pixels
| 8/13MP(flash light)
|
AUDIO
| Speaker
| Dual box(8Ω/1W, Quad box optional)
|
Microphone
| MICx1
|
FM
| Yes
|
SENSOR
| G-sensor
| Yes
|
Distance sensor
| optional
|
Light sensor
| optional
|
Gy-sensor
| optional
|
M-sensor
| optional
|
COMMUNICATION
|
Type
| Item
| Description
|
INTERACTION
| LTE/3G/2G
| Yes
|
WiFi
| 802.11ac/a/b/g/n 2.4G+5G
|
Bluetooth
| BT5.0
|
GPS
| GPS /Galileo/Glonass/Beidou
|
CONNECTION
|
Type
| Item
| Description
|
SLOT
| SIM/Micro SD card
| Nano SIM*2(Nano SIM*2 or Nano SIM+MicroSD)
|
INTERFACE
| Type
| Type-C*1, 3.5mm headphone jack*1, USB docking*1
|
BUTTON
| Type
| POWER key,Vol+ key,Vol- key,Reset key
|
SERVICES
OEM Services
•Logo silk printing & laser carving on shell(plastic/metal), Touch panel(with MOQ 5000pcs) and Accessories(pack box/user manual/warranty card/power adapter/protective case,etc.);
•System customization(boot animation/wallpaper/system discription/software rename/pre-insall Apps etc.)
ODM Services
After-sale Service
•1-year warranty for all products(excluding accessories). Any quality issue(excluding wrong operation or other human factors) can get repaired or components replaced.
•If customers solves the after-sale problems on their own, Pretech will give full technical support and advice on repair or replacement. If necessary, we will send technician to help.
•Technial support for whole life of our products.
FAQ
Q: How to get samples?
A: We do not provide free samples. If you want samples for test, please tell us your company background, the details of your related projects and the purchasing plan, thanks. We will evaluate and decide to provide samples.
Q: How can I get price list?
A: Please send us offers with full contact information(email/phone number, etc.), we will contact you.
Q: How to start my ODM projects?
A: First, pease give us a full introduction of the projects, including product type, application, and other special requirement. Then we will send you the project investigation table to fill, with this table received from you, we will evaluate, make the BOM and give you solution and quotation. In all, we should be very patient and understand each other with full communication.
Q: How to make the payment?
A: For an order, usually we require 30%~50% down payment, and the balance should be paid before delivery by T/T, Westunion, Paypal, or L/C at sight.
>>
