Product Details
Product Description
Product Description
Features:
1.This solar cell laser scribing machine is fully enclosed design, with dust cover, it can avoid environmental pollution, to prevent the operator's vision damage.
2.Software upgrade: the solar cell laser scribing machine support the arc interpolation,circular arc cutting more smoothly.
3.The wafer scribing machine upgrade: covers an area of space smaller after modification, operating more accord with human body engineering.
4.Refactoring workbench processing part, open-type workbench processing area, up-down material more convenient. Removed spare parts from the workbench tablet, higher precision and not easy to deformation.
5. Improvement the screw parts of solar cell laser scribing machine: screw lead increased, so as to expedite the processing speed, guarantee machining accuracy.
6. Direct plug-in light path design of the solar cell cutting machine, higher machining precision, better effect .
7.Serve motor modification: run more smoothly, smaller cutting noise,more humanized design;
8.Authoritarian flat dust removal device: the processing effect of the solar cell cutting machine is better.
9.Improved the laser signal control section of the solar cell cutting machine, software runs more stable and fast.
Technical Data:
Model specification
| PE-50WII Laser Scribe Machine
|
Laser wavelength
| 1064nm
|
Laser power
| 50W Raycus Laser Source
|
Scribing line width
| 50um
|
Scribing speed
| 240mm/s
|
Scribing precision
| ±10um
|
Workbench wide
| 200×200mm
|
Temperature control precision
| 0.5℃
|
Working power supply
| 220V/50Hhz/1.5KVA
|
Workbench
| Cell automatic adsorption, dust removal
|
Cooling way
| High precision and constant temperature circulating water cooling professional integration
| Air cooling
|
>>
