Best Service 100 a AMP Plasma Cutter Cutting Machine

US$249.00-349.00 10 Pieces (MOQ)

Basic Info.

Model NO.

CUT-100

After-sales Service

One Year

Warranty

One Year

Customized

Layout

Horizontal

Cutting Material

Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel

Automatic Grade

Manual

Power Source

Electric

Cutting Mode

Plasma Cutting

Model

Cut-120

Rated Input Voltage(V)

AC 380

Rated Input Current(a)

Open Circuit Voltage(V)

310

Rated Output Current(a)

120

Rated Load Endurance @ 40ºC

60%

Air Pressure Regulating

0.6-0.65

Cutting Thickness

1-45

Insulation Class

N.W/G.W(Kg)

30.6/36.3

Dimensions(mm)

624*415*530

Loading Q′ty(20gp/40hq)

196/410

Protection Grade

IP21s

Transport Package

Carton Box

Specification

Dimensions(mm): 624x 415 x 530

Trademark

Cameo

Origin

Chongqing, China

HS Code

8456401000

Production Capacity

20000unit/Month

Product Description

Model	CUT-40	CUT-60	CUT-80	CUT-100	CUT-120
Rated Input Voltage(V)	AC 220	AC 380	AC 380	AC 380	AC 380
Rated Input Current(A)	32	17	23	33	42
Open Circuit Voltage(V)	240	260	280	300	310
Rated Output Current(A)	40	60	75	100	120
Rated Load Endurance @40ºC	60%	60%	60%	60%	60%
Air Pressure Regulating	0.3-0.35	0.35-0.45	0.45-0.5	0.5-0.6	0.6-0.65
Cutting Thickness	1-10	1-15	1-25	1-40	1-45
Insulation Class	F	F	F	F	F
Protection Grade	IP21S	IP21S	IP21S	IP21S	IP21S
N.W/G.W(KG)	7/9.9	11/14.5	21/26	29/34.5	30.6/36.3
Dimensions(mm)	450x270x345	535x305x410	585x375x500	624x415x530	624x415x530
Loading Qty(20GP/40HQ)	630/1300	395/820	232/490	196/410	196/410

Here is brief introduction of Camel Power as below:
* 20 years' experience in general machine industry.
* the company has its own workshop with an area of more than 50000 square meters and more than 200 employees.
* It has five automatic production lines and advanced online inspection equipment, with an annual production capacity of more than 500,000 units.
* Our products have been exported to nearly 100 countries and regions around the world.
* Main products: generator sets, welding machine, water pump, air compressor and other terminal series
