Custom Bare Fiber Optic Pigtail Connector Patchcord Ar Hi-Reflection Coating

Product Description

Bare Fiber Coating
Bare Fiber Coating means laying optical thin film on the bare fiber end face to increase light transmission or reflection.
3V TECHNOLOGY succeed in polishing bare fiber without any epoxy and coating optical precision thin film to the fiber tip,which improve the product quality significantly.
Product Application:
-Fiber laser pump diode coupling
-High power laser processing flexible transmission
-Medical laser equipment coupling transmission
-Fiber optic Sensor(Connecting Photoelectric detector)
Product Features:
-The fiber tip is directly polished without any epoxy in the process,which can aviod laser absorption caused by epoxy residue and reduce the fiber burn rate efficiently.
-High quality fiber tip polishing surface,without scratches and particles on the fiber core.-Coat only on the bare fiber tip(without ferrule&epoxy),which can eliminate film cracking caused by inconsistent thermal expansion coefficients of different substrates under the coating layer.
-Avoid the impact of the ferrule and epoxy on the laser chip at a close distance,effictively reducing COD and chip Contamination.
-Low heat absorption and high laser damage threshold of coating layer,Optical damage threshold(>200MW/cm2,test by quantel USA)
Fiber Patchcord Coating
SMA905 Fiber Patchcord utilize high precision SMA905 connector or air-gap-ferrule connector.It is equipped with high quality tip polishing surface fiber.The Patchcord mainly used for energy transmission of semiconductor laser modules and medium-low power solid state lasers.The internal connector of the fiber patch cord apply high-quality environment epoxy free technology,which improve the heat dissipation effect and service life of the fiber.The SMA905 Patchcord can meet the demand for laser welding,cutting and other high power transmission.3V TECHNOLOGY also offer custom patch cable services and accpet fiber cable(sunc as D80 jumper,FC/PC patch cord) coating services.
Product Application:
-Pump laser fiber tail and fiber patch cord.
-High power laser processing energy transmission.
-Medical laser equipment.
-Industrial laser processing
Product Features:
-3V-TECHNOLOGY's unique fiber polishing and assembling process.
-The fiber patch cord is made if imported high quality large-core optical fibers.
-AR coated fiber end face,demage threshold up to 200mW/CM2.
-Stainless Steel Protective Tubing Design,resists crusing,abrasion,cutting,and pulling.
-The SMA ferrules are made of stainless steel or cupronickel and used as a heat sink,evacuating the heat quickly away from the fiber.
-Utilize air-cap-ferrule technology that eliminates energy-absorbing materials near the fiber end face sunc as epoxies,connector material,and coating,making them ideal for high-power applications.

Fiber Patchcord Coating
D80 Optic Fiber Patchcord utilize high precision D80 connector or air-gap-ferrule connector.It is equipped with high quality tip polishing surface fiber.The Patchcord mainly used for energy transmission of semiconductor laser modules and medium-low power solid state lasers.The internal connector of the fiber patch cord apply high-quality environment epoxy free technology,which improve the heat dissipation effect and service life of the fiber.The D80 Patchcord can meet the demand for laser welding,cutting and other high power transmission.3V TECHNOLOGY also offer custom patch cable services and accpet fiber cable(sunc as SMA905 jumper,FC/PC patch cord) coating services.
Product Application:
-Pump laser fiber tail and fiber patch cord.
-High power laser processing energy transmission.
-Medical laser equipment.
-Industrial laser processing
Product Features:
-3V-TECHNOLOGY's unique fiber polishing and assembling process.
-The fiber patch cord is made if imported high quality large-core optical fibers.
-AR coated fiber end face,demage threshold up to 200mW/CM2.
-Stainless Steel Protective Tubing Design,resists crusing,abrasion,cutting,and pulling.
-The SMA ferrules are made of stainless steel or cupronickel and used as a heat sink,evacuating the heat quickly away from the fiber.
-Utilize air-cap-ferrule technology that eliminates energy-absorbing materials near the fiber end face sunc as epoxies,connector material,and coating,making them ideal for high-power applications.

---
