Jinzong Coffee Powder Mixer Mixing Machine

Product Description

Food & Cosmetic Machine: V-shape mixer
1.Mix dry powders or granules
2.Eveness to 99%
3.Conform to GMP standard

2.Food & Cosmetic Machine V-shape mixer is suitable for mixing the dry powder and granule which belong to flowing materials. The machine consists of two asymmetric barrels where the materials would be moved longitudinally and transversely so that the mixing evenness can be over 99 percent. The mixer can be equipped with vacuum suction system with which the materials can be sucked into the mixing barrels and mixed under hermetic condition. There is no driving mechanism inside the mixer so that it is very clean and meets GMP standard.
3.Parameter of Laboratory V shape Mixer:

V-shape Mixer
Type	Design Capacity	Working Capacity	Power	Speed(r/min)	Size(mm)	Max Loading Capacity	Weight(kg)
VH5	5L	2L	0.55kw	24r/min	515*430*650mm	2kg	50
VH8	8L	3.2L	0.55kw	24r/min	620*520*660mm	2.5kg	60
VH14	14L	5.6L	0.55kw	20r/min	1000*460*920mm	4kg	90
VH20	20L	8L	0.55kw	20r/min	1250*350*1100mm	6kg	120

4.Parameter of Big Scales Production V shape Mixer:

V-shape Mixer Specification
type	VH-100	VH-300	VH-500	VH-1000	VH-1500	VH-2000	VH-2500	VH-4000
Production Capacity	30	80	100	200	300	400	400	800
(kg/h)
Pump type	W2	W2	W3	W3	W3	W4	W4	W5
Feed time(min)			4-6min	6-9min	6-10min	12-18min	12-18min	12-18min
Mix time(min)	4-8min	6-10min	6-10min	6-10min	6-10min	6-10min	6-10min	6-10min
Vol.(m3)	0.1	0.3	0.5	1	1.5	2	2.5	4
Speed(r/min)	12	12	10	10	10	10	10	8
Motor Power(kw)	1.1	1.1	2.2	4	4	7.5	7.5	11
Dimension	1780×650×1750	1800×650×1850	2500×1220×2420	2975×1600×3000	3190×1600×3000	3800×1900×3310	3990×1990×3790	4945×2200×4230
(LWH)(mm)
Height	1750	1850	2450	3000	3100	3700	3790	4160
Weight(kg)	250	320	550	950	1020	2000	2040	2800

---
