Ck5112D Single Column CNC Vertical Lathe Machine

US$50,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
CK5112D
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
/
Control Method
/
Numerical Control
CNC/MNC
Processing Precision
/
Performance Classification
High-End CNC Machine Tools
Certification
CE
Transport Package
Carton Packing
Specification
/
Trademark
DMTG
Origin
Liaoning
Production Capacity
10 Sets/Month

Product Description

Hot Selling Vertical CNC Lathe Machine With Factory Direct Sale Price
Item Unit CK5112D CK5116D CK5120D CK5123D CK5125D CK5126D CK5131D
Max. cutting dia. mm 1250 1600 2000 2300 2500 2600 3100
Max. cutting height mm 1000/1200 1000/1200/1400 1250 1350 1600 1600/2000 1600
Loading weight T 3.2 5 8 8 10 10 10
Worktable dia. mm 1000 1400 1800 2000 2250 2250 2830
Worktable speed range rpm 6.3-200 5-160 3.2-100 3.2-100 2-63 2-63 0.5-63
Worktable Step Range --- 4 gear shift stepless / 11 gearshift stepless
Worktable max. torque N.m 25000 32000 32000 32000 35000 35000 40000
Vertical tool head cutting force N 20000 25000 25000 25000 25000 25000 30000
Vertical tool head vertial travel mm 650 800 800 800/1000 800/1000 1000/800 1250
Vertical tool head horzontal travel mm 700 1050 1190 1320 1420 1500 1900
Turret rapid travel speed mm 20000
Tool bar size mm 32*32/40*40 32*32/40*40 32*32/40*40 32*32/40*40 40*50/32*32 40*50/32*32 40*50/32*32
Cross beam travel mm 650/850 650/850/1050 850 1000 1200 1200/1600 1250
Crossbeam lifi speed mm/min 440
Machining precision --- IT7
Positioning precision mm 0.03
Repositioning precision mm 0.015
Main motor kw 22 30 30 30 37 37 55
Machine weight t 8.5/9.5 12.4/14/14.8 17 18 24 24/26 30
Overrall dimension (L*W*H) mm 2360*
2280*2800		 2830*
2670*3010		 3200*
2800*3250		 3210*
2850*3300		 3300*
4000*3500		 3300*
4000*3500		 4400*
4000*3800
