Product Details
Product Description
Product Description
1. Windows 7/8, machine with self-owned intellectual property ;
2. Automatic adjustment for height of camera beam , automatic tracking the target plates ;
3. Automatic checking for height of car lift , automatic calibrate the camera ;
4. With black-box functions , all files can be saved for future analysis ;
5. Quicker running for alignment with guiding menu ,can read database within 3 minutes ;
6. 3D animated measurement , easy for training and operate ;
7. Available for OEM vehicle database ;
8. Manual enter height of vehicle ;
9.“ MKS” measurement special for Benz ;
10. Available for single-wheel positioning ,two wheel positioning , four wheel positioning ;
11. 26kinds of language for different countries and districts ;
12. Adjustment function for FORD bushing ;
13. Instruction function for North star shims ;
14. Measurement for Caster Trail ;
15. Measurement for Scrub Radius & SAI ;
16. Cradle Adjust of motor ;
17. A-Arm resetting on turntable ;
18. Adjustment for Camber at Zero Toe
19. Drag Link Adjust to ensure the steering wheel in the middle
20. Single Tie Rod Adjust
Technical data:
Item
| Accurancy
| Range
| Total range
|
Camber
| ±0.02°
| ±10°
| ±10°
|
Caster
| ±0.05°
| ±10°
| ±10°
|
KPI
| ±0.02°
| ±20°
| ±20°
|
Toe
| ±0.02°
| ±2.4°
| ±4.8°
|
Rear axle offset
| ±0.02°
| ±2°
| ±4°
|
Max steering angle
| ±0.08°
| ±20°
| ±45°
|
Thrust-angle
| ±0.02°
| ±2°
| ±4°
|
Track with difference
| ±0.03°
| ±2°
| ±8°
|
Front setback
| ±0.02°
| ±2°
| ±4°
|
Rear setback
| ±0.02°
| ±2°
| ±4°
|
Track width
| ±0.64cm(±0.25cm)
| <265cm(<105in)
| <265cm(<105in)
|
Wheel base
| ±0.64cm(±0.25cm)
| <533cm(<210in)
| <533cm(<105in)
|
Company Picture:
Our service:
1) Warranty: 36 months;
2) Delivery time: 3-5 working days after payment received;
3) 1set sample order is acceptable;
4) Method of payment: T/T , TRADE ASSURANCE;
5) Certificate: TUV , ISO , CE.
>>
