US$80,000.00-900,000.00
|
1 Set
(MOQ)
|
Basic Info.
Certification
ISO9001: 2000, CE
Degree of Automation
Automatic
Stirring Method
Continous Drum
Target Audience
Cement Concrete Pavement
Transport Package
International Standard Packing
Specification
36000*15000*21000mm
Production Capacity
800 Set/Sets Per Month
Product Description
Function
Our concrete mixing plants can be widely used in construction projects like buildings, roads, bridges, high way roads, municipal projects,docks, airport, water projects, hydropower station,etc. They can also be used in precast concrete unit factories and used as commercial concrete batching plant to sell high quality concrete to different buyers.
Features
1.Reliable mixing quality, high production efficiency, stable and long lifespan;
2.Advanced technology, strict production technique, high safety;
3.Digital weighing, high weighing accuracy, advanced centralized control system, zero repair;
4.Integrated design, flexible layout, space saving, environmental protection;
5.All motors, speed reducers, sensors and other components are of China famous brand.
Technical Data:
Model | | HZS60 | HZS90 | HZS120 | HZS180 | HZS240 |
Mixer | Productivity(m³/h) | 60 | 90 | 120 | 180 | 240 |
Type | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 |
Power(kw) | 2x22 | 2x30 | 2x37 | 2x55 | 2x75 |
Output(m³) | 1 | 1.5 | 2 | 3 | 4 |
Aggregate Diameter (mm) | ≤800 | ≤100 | ≤120 | ≤150 | ≤150 |
Batching Hopper | Hopper Volume(m³) | 3X13 | 4X13 | 4X15 | 4X20 | 4X20 |
Hopper Quantity | 3 | 4 | 4 | 4 | 4 |
Belt Conveyor Capacity(t/h) | 200 | 200 | 300 | 400 | 400 |
Weighing Scope and Accuracy | Aggregate(kg) | 4×1500±2% | 4×2000±2% | 4×2200±2% | 4×3600±2% | 4×3600±2% |
| Cement(kg) | 600±1% | 900±1% | 1200±1% | 1800±1% | 2400±1% |
| Fly-ash (kg) | 200±1% | 300±1% | 400±1% | 600±1% | 800±1% |
| Water (kg) | 250±1% | 400±1% | 500±1% | 800±1% | 1000±1% |
| Admixture(kg) | 20±1% | 30±1% | 30±1% | 50±1% | 80±1% |
Total Power(kW) | 82 | 108 | 127 | 178 | 220 |
Discharge Height(m) | ≥3.8 | ≥3.8 | ≥3.8 | ≥4 | ≥4 |
Note: 1,The total power excludes the power of screw conveyor; 2,The quantity and volume of hopper can be designed as required; 3,All above specifications are subject to final products. |
Accesaries Equipments: Including batching machine, conveyer belts, mixing machine, control room, cement silo and so on.
>>
