DONGYI DY-12kg coffee roaster (Electric/Gas type)
*1 year sold 2000+ to the world
*Germany technology made by Military production
*Electronic speed governor for HOT AIR [JMC TOP BRAND]
*ADDKA superior motor with OMRON VFD converter speed control [TOP BRAND]
*310SUS double wall drum/cast iron drum option
*Artisan roasting data logging [Bluetooth connect computer]
*25℃+ warm up temperature rate per minute
*Cast Iron gas burner [gas roaster]
*Carbon fiber heating tube [electric roaster]
*CE、ISO9001:2000
Roaster Size
| 1700*720*1640 mm
|
Roaster Weight
| 580kg
|
Chaff Collector Size
| 597x1409 mm
|
Chaff Collector Weight
| 50 kg
|
Drum Construction
| Double-walled Drum, 310 Stainless Steel, Welded
|
Batch Size
| 2-13kg
|
Average Roasting Time
| <12-15 minute batch
|
Power
| Single Phase, 220V, 15A, 50-60Hz
|
Step-Up Transformer
| 120V to 220V, 1000W
|
VFD speed control on drum and air motor
| OMRON inverter （TOP BRAND）
|
Drum Motor
| 400W ADDKA(TOP BRAND)
|
Exhaust Fan Motor
| 400W
|
Cooling Fan Motor
| 750W
|
Cooling Tray Stirring Motor
| 200W ADDKA(TOP BRAND)
|
Electric roaster add heating power as
| 18kw 【gas roaster havent】
|
Fuel Type
| LP Gas -or- Natural Gas/Electric
|
Max. BTU
| 90,000
|
Burner Control
| Manual Valve
|
Gas Connection
| 1/2" NPT
|
Gas Pressure Required
| LP Gas: 7” of water column
Natural Gas: 11” of water column
|
Gas Orifices Size
| LP Gas: 0.7 mm (installed at factory)
Natural: 0.9 mm (see conversion/instructions)
|
Max Gas Usage
| 3.3 lb/hr (1.5 kg/hr)
|
Typical Roaster Exhaust High Temp
| 400°F - 450°F
|
Max Exhaust
| 600 CFM
|
Exhaust Venting Type Required
| Class III, Positive Pressure
|
Bluetooth
| Modbus CP210/artisan software
|
Logging Thermocouples
| BT, ET, Incoming Air
|
