HDPE Plastic Dimpled Board Extrusion Making Machine, HDPE Plastic Dimpled Board Production Line

Product Description

HDPE plastic dimpled drainage Board making machine
Description of HDPE plastic dimpled drainage Board making machine:
HDPE plastic dimpled drainage board making machine (Dimpled waterproof drainage board production line) is to product the dimpled drainage board, it with high automatic and stable output. All the control system is used PLC, very easy to operate.
The dimpled are forming trough the vacuum.
This production line product is a plastic dimpled drainage board, which used in various waterproof and drainage application.
Features of HDPE plastic dimpled drainage Board making machine:
1) Can production of many colors and many series of dimpled drainage sheet.
2) Complete automation machine to save the time and labor.
3) Different molds to produce different size dimpled drainage sheet, the dimple's height can be 6mm, 10mm, 15mm, 20mm or according your require.
4) Specially designed roller to ensure the precise thickness of the dimpled sheet, that to reduce the wasting raw material.
Photos of HDPE plastic dimpled drainage Board making machine
Overview of HDPE plastic dimpled drainage Board making machine
extruder of HDPE plastic dimpled drainage Board making machine
Formming roller of HDPE plastic dimpled drainage Board making machine
Haul-off machine of HDPE plastic dimpled drainage Board making machine
Cutter and windder of HDPE plastic dimpled drainage Board making machine
Final dimpled sheep product from HDPE plastic dimpled drainage Board making machine
Final dimpled sheet with coating geotextile from HDPE plastic dimpled drainage Board making machine
Parameter of HDPE plastic dimpled drainage Board making machine:

Type	WD-1000	WD -2000	WD -3000	Custom-made
Extruder	SJ-90	SJ-120	SJ-150	According the size
Screw diameter(mm)	90	120	150	According the size
L/D ratio	30-33:1	30-33:1	30-33:1	30-33:1
Motor power(kw)	55	90	132	According the size
Control method	Frequency conversion
Width(mm)	1000	2000	3000	According the size
Roller cooled medium	Water
Total power(kw)	82	156	228	According the size

About HDPE dimpled waterproof drainage board
Waterproof drainage sheet Applications:
Polyethylene (HDPE) plastic drainage board against the application as follows:
Garden Project: garage roof greening, roof garden, green roof, soccer fields, golf courses, beach projects
Municipal engineering: road embankment, subway tunnels
Construction: building the basis of the upper or lower, basement and outside walls, roof and insulation and other impervious
Traffic Engineering: roads, railway embankment, embankment and slope protection layer
The final HDPE board is a dimpled plastic sheet that can be used in various waterproofing applications. The dimpled nubs create a vapour and thermal insulation barrier for both internal walls and walls that are adjacent to waterproofing sheets, while also protecting the waterproofing sheet from the backfill in underground structures.
The Drainage board offer protection against any dampness in ground slabs and also create a cavity control layer, while The integrated non-woven geotextile covering the nubs prevents soil particles blocking the drainage sheet, creates an air gap for reliable ventilation and allows inflow and transport of water from surrounding soil.
Wedo Produce steps:Wedo have a fully step for the HDPE plastic dimpled drainage board making machine producing before packing and shipping, this ensure the plastic recycling machine will delivery in good quality, and custerm will get good machine.Wedo service:We do best service for you in HDPE plastic dimpled drainage board making machineAny further about the HDPE plastic dimpled drainage board making machine, please contact us timely we will give your professional fully support.

---
