Product Description
Product Description
New energy and green travel have become a new way of life, and charging piles are increasingly appearing in our lives. Standard electric vehicle DC (AC) charging pile cables have become the most important "heart" of charging piles .
The DC charging pile is commonly known as "fast charging". During the charging process, the input voltage of the DC charging pile adopts three-phase four-wire AC380V±15%, the frequency is 50Hz, and the output is adjustable DC, which is directly the power of the electric vehicle. The battery is charged, and the requirements of fast charging can be realized.
The AC charging pile is called "slow charging", which only provides power output and has no charging function. It needs to be connected to the on-board charger to charge the electric vehicle, which is a requirement for a large amount of charging pile cables.
Standard electric vehicle DC charging pile cables are used in charging pile systems, floor-mounted charging piles, wall-mounted charging piles and other places, where the voltage is 1KV (DC), the test voltage is 6000V/min (DC), and the fixed laying: 4 × outside the cable Diameter, mobile installation: 7.5× cable outer diameter or smaller temperature range, fixed installation: -50℃～90℃, mobile installation: -40℃～90℃.
Performance requirements of charging pile cables:
1. Oil resistance. It needs to have good acid, alkali, solvent and excellent performance of various hydraulic oils.
2. Weather resistance. Since the charging pile cable is often used outdoors, it needs to have good UV resistance, UV resistance, sunlight aging and other properties.
3. It needs to have good flame retardant properties.
Characteristics of charging pile cables
1. The cable has high voltage resistance, high temperature resistance, electromagnetic interference resistance, stable signal transmission, wear resistance for more than 50,000 times, oil resistance, water resistance, acid and alkali resistance, and UV resistance for signal control and transmission network systems such as voltage and current during the charging process. and other characteristics.
2. The concentricity is good, up to more than 80%, which makes the cable's high-voltage resistance performance stable and reliable.
3. The minimum bending is 4D, which is convenient for use between corner wiring in narrow spaces. The product has high flexibility and is very convenient for vehicle wiring.
4. The rated temperature is 125°C, which is a great technical progress and improvement for the use of one-shot soft-grade insulating materials, and is very important to ensure the flexibility of the cable and improve the current carrying capacity of the cable.
To learn more about new ev cable and ev charging cable, please visit OMG's official website: /
>>
