AT451 Differential Scanning Calorimeter (DSC) is used to determine and research the melting and crystallization process, glass transition temperature, oxidation induction time (OIT), reaction heat, heat enthalpy, melting point, phase transition, etc.Principle:The difference between the heat flux into a test specimen and that into a reference specimen is measured as a function of temperature and time, while the test specimen and the reference specimen are subjected to a controlled temperature programme under a specified atmosphere.
Standard
ISO 11357
| ASTM E794
| GB/T 13464, 19466
|
Note: For more standards, please contact us
|
|
|
Specification
Model
| AT451
|
DSC range
| 0～±500mW
|
Temperature range
| RT~800℃, air cooling (standard configuration)
|
Heating speed
| 1~60℃/min
|
Temperature resolution
| 0.1℃
|
Temperature fluctuation
| ±0.1℃
|
Temperature repeatability
| ±0.1℃
|
DSC resolution
| 0. 05μW
|
DSC accuracy
| 0.05μW
|
DSC sensitivity
| 0.05μW
|
Temperature control mode
| Heating up, keeping temperature, cooling down (program control)
|
Display mode
| LCD touch screen
|
Data interface
| USB
|
Power supply
| AC220V, 50Hz
|
Details & Features
Machine operation interface
★ Suitable for solid, powder and liquid samples, except gas sample.★ LCD display, touch screen operation.
★ Full equipped with accessories, convenient and easy to test.★ Chinese or English operation system can be selecte
The back of machine
★ In-built atmosphere device, can simultaneously connect with Nitrogen and Oxygen, automatic switchover. With USB cable to connect machine to computer.
Flow meter
★ Full equipped with accessories, convenient and easy to test.
★ Chinese or English operation system can be selected.
★ Small furnace, high accuracy of temperature control, the temperature can be RT~800℃. Also, liquid nitrogen cooling system can be optional, the temperature can be -100 ~ 800℃ or -20 ~ 600℃.Test interface for DSC tes
Test interface for DSC test
★ Two user interface on software, one is for DSC test, the other is for OIT test
DSC-Temp curve for melting point test.
★ Real-time record and display DSC-Temp curve or DSC-time & Temp-time curve
.
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging
|
|
Dimensions
| 1160x510x1050mm
|
Weight
| Approx. 80kg
|
Packaging Details
| 1. The equipment is covered with film is protect it from water vapour during the trip.
2. The box is filled with foam to protect the equipment from impact.
3. Exported wooden box made from plywood, don't need fumigated.
|
Payment
Payment Term
|
T/T
| EXW
|
30% T/T in advance, paid the balance before shipment
|
|
| FOB
|
|
|
| CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L
|
|
| CIF
|
|
| L/C
| L/C amount above 50,000 usd, we can accept L/C at sight
|
|
| West Union
|
Amount lower than 5000usd
|
|
| West Union
|
|
|
Delivery Time
| 7~10days after receiving payment for one container
|
|
|
