US$5,680.00-39,800.00
|
1 Set
(MOQ)
|
Basic Info.
Application
Liquid, Viscous Fluid
Application Area
Chemical
Control System
Button/PLC Control
Cooling Method
Water Cooling
Heating Method
Electric Heating
Mixing Drum Shape
Circular Groove
Speed Control
Variable Speed
Speed Range
60 R/min & Above
Temperature Control
With Cooling System
Emulaifier System
Botton/Top Homogenizer
Homogenizer Speed
0-3000rpm
Mixing Method
Frame Type Two-Way Wall Scraping Spiral Impeller
Operating Type
Continuous Operating
Transport Package
Wooden Case
Origin
Guangzhou Guangdong China
Production Capacity
25-35 Set Per Month
Packaging & Delivery
Package Size
280.00cm * 260.00cm * 200.00cm
Package Gross Weight
1000.000kg
Product Description
Product Description
Stationary Vacuum emulsifier Mixer is a kind of equipment for mixing and homogenizing materials in vacuum state. It usually consists of a stationary container and a rotating mixing paddle. At work, the material in the container will be fully mixed by the stirring paddle in the vacuum state, so as to achieve a uniform effect. This device is usually suitable for materials with high viscosity or high solid content, such as cosmetics, food, medicine and other industries.
1.The material contact part adopts SS304/SS316
2.the accessories use international famous brands, such as ABB motor and Delta inverter,
3.the mixer 0-60RPM and homogenizer 0-3000RPM speed can be adjusted
4. The homogenizer is mainly used in food, chemical, pharmaceutical and other fields, for material mixing, homogenizing, heating treatment. Commonly used in the preparation of lotions, creams, sauces and other products. Product Parameters
| Model | Capacity(L) | Mixing | Homogenizing |
| Power(kw) | Speed(r/min) | Power(kw) | Speed(r/min) |
| WJ-V50 | 50 | 0.75 | 0-60 | 1.5 | 0-3000 |
| WJ-V100 | 100 | 1.5 | 0-60 | 3 | 0-3000 |
| WJ-V200 | 200 | 2.2 | 0-60 | 4 | 0-3000 |
| WJ-V300 | 300 | 3 | 0-60 | 7.5 | 0-3000 |
| WJ-V500 | 500 | 4 | 0-60 | 11 | 0-3000 |
| WJ-V1000 | 1000 | 5.5 | 0-60 | 15 | 0-3000 |
| WJ-V2000 | 2000 | 7.5 | 0-60 | 18.5 | 0-3000 |
| WJ-V3000 | 3000 | 11 | 0-60 | 22 | 0-3000 |
| WJ-V5000 | 5000 | 15 | 0-60 | 37 | 0-3000 |
Detailed Photos
