Automatic Pet Bottle Making Machine for Juice Bottle/ Pet Bottle Blow Molding Machine Manufacturers

Product Description

Automatic pet bottle making machine for juice bottle/ pet bottle blow molding machine manufacturers
Specifications:
automatic blowing machine
CE approval
Speed: 2500pcs/h for 500ml pet bottle
Volume:100ml-2500mL
Brief introduction of water bottle blow molding machine:
1.The machine is the fastest liner blow molding machine in mainland of China by now. Its baking tunnel is separated from the blow station so that time for mold opening is shortened with a result of speedy blowing and high output, damage to machine is lessened so as to keep reliable performance and prolong service life, as well as machine runs more smoothly and steadily.
2.Automatic stretch blow molding machine is equipped with patented preform loading system, which consists of two manipulators: rectilineal manipulator and overturning manipulator. The rectilineal manipulator moves preform with neck up to the preform holder, after heating, the overturning manipulator grips heated preform and overturn 180 put preform to blow station with neck down. After stretching and blowing, the bottle is taken off by overturning manipulator. The specially designed preform loading & bottle discharging system avoid possible damage to preform & bottle during transportation.
3.Controlled by PLC. The whole process from preform feeding to bottle discharging is completed automatically with advantages of labor saving and no pollution.
4.Consists of three main parts: preform loading system, Heater channel & blow station.

Main technical parameter:

Model	Item	LFD-A2	LFD-A4	LFD-A6
Productivity	Depend on bottle design	1800-2700pcs/h	3200-4000pcs/h	4000-5500pcs/h
Bottle specification	Volume	0.1-2.0L	0.1-2.0L	0.1-2.0L
	Body diameter	≤100mm	≤100mm	≤100mm
	Height	≤300mm	≤300mm	≤300mm
	Neck diameter	28mm-38mm	28mm-38mm	28mm-38mm
Mold	Cavity	2	4	6
	Mold thickness	240mm	240mm	240mm
	Mold volume	260*240*370mm	510*240*360mm	640*240*360mm
Main machine power	Rated power	25kw	49kw	73kw
	Usage power	6.5kw	13kw	25kw
Air system	HP air compressor	1.4m3/min 3.0MPa	2.0m3/min 3.0MPa	6.0m3/min 3.0MPa
	LP air compressor	1.0m3/min 1.0MPa	1.6m3/min 1.0MPa	2.0m3/min 1.0MPa
	Air tank	0.6m3 3.0MPa	0.6m3 3.0MPa	1.0m3 3.0MPa
	Air dryer	1.0m3/min 3.0MPa	2.0m3/min 3.0MPa	6.0m3/min 3.0MPa
Cooling water system	Water chiller	3HP	3HP	3HP
Main blowing machine	Size(L*W*H)	1900*1280*1930mm	1900*1860*1930mm	4100*2400*1930mm
	Weight	2000kg	3600kg	4200kg
Preform unscrambler	Size(L*W*H)	2000*950*2480mm	2000*950*2480mm	2000*950*2480mm
	Weight	250kg	250kg	250kg

Packaging & Shipping:
Our service: Before the order:
We will make detailed solution for you based on your requirments.
We will send you videos of our products to know more about our machines.
If you are willing to visit our factory,we will pick you up at a nearby airport/station
After the order:
We will start to produce machines and update the progress.
Our engineer will draw the layout for you.
After-sales service:
Arrange our engineer to your factory to install machines if you need,train your employee until they can operate machines well.
Provide you 2 years warranty with spare parts 2 year free.
24 hours for engineer response (all services part 5days in customer hand by Intl' courier)
FAQ:
Q1:Are you a trading company or a manufacturer ?
A1:We are the manufacturer ,we produce machines ourselves,we can assure the quality.
Q2:What is your advantage?
A2:Competitive price , Excellent technical support ,24h online service
Q3:When can I get my machines after I paid?
A3:We will arrange delivery on time,act according to the contract.
