Toe Lasting Shoes Making Machine with Competitive Price

Product Description

DS-618AM Automatic Cementing & Toe Lasting Machine for shoe
This machine is applicable for lasting the toe of all kinds of man and lady shoes and sports shoes with automatic cementing.
The crosshead projection light will ensure accurate last positioning.
The pressure head mechanism adopts adjustable two-segment pressure to ensure steady pressure and achieve the best pressing result.
The all-round band and wiper with special tracking system make sure that each part of the upper is tightly against the shoe last after lasting without any point angle but with smooth appearance.
The 9 independent pincers can be adjusted independently.
The pincer plate can be also adjusted synchronously according to the shoe size
The pincers of number 2 and 5 have independent adjusting device to adapt to different types of last rapidly and accurately to ensure the minimum interval between each pincers and make sure it is free of any angles.
The pressure, position, and speed of each device may be adjusted from outside directly and conveniently.
The uniquely designed internal and external supporting device can be quickly adjusted to the relative position between it and the middle pincer in accordance with the shoe size.
The automatic glue feeding device may also adjust the glue feeding amount according to the lasting requirement.
1,Characteristics
DS618AM Automatic Toe Lasting Machine with Cementing is a clamping shoe vamp with nice claws molding machine, designed for shoe sole molding. Make use of this machine to manufacture your products, which can meet the demand of attaching shoe vamp with the shoe last smoothly. The machine is featured with convenient operation, high efficiency, steady quality, easy maintenance, and suit for manufacturing the children shoes, sports shoes, lady shoes, men shoes, riding boot, gentlemen shoes and other special work shoes, mountaineering shoes and so on.
(1) Main features:
1. Universal tightening band and specially-designed wiper ensure shoe vamp attaching shoe last equably without any shagginess after lasting.
2. Pressure head device adopts adjustable two-sections pressure, which make the working piece during wiper tightening and final pressing reach the best impression.
3. Independence nice claws is adjustable, which can be suit for any shape shoes toe part tightening .
4. The Inner supporter is designed to rise up two times, which is very suitable for the upper with less margin.
5. Each claw has function of automatic cogging-down. Operator can select some claws to be cogged down according with shoe vamp tightness degree.
6. Wiper with function of adjustable speed and inching motion is convenient for adjustment that controlled vamp tightening.
7. Auxiliary wiper structure cooperating with nice claws of toe part make the vamp attaching shoes last tightly.
8. Cross projection lamp can help laying toe part of shoe last in the right position.
9. Opening or closing of turn-plate of right and left claws is adjustable and independence, which can manufacture the right and left shoe separately.
10.Rotating of second claw is independence and adjustable, which is more quick and convenient for replacing shoe last.
11. Adjustable inner and outer supporter can move upward or downward, which is convenient for manufacturing shoes with any size.

2,Main Parameters

Motor Power	2.2 kW	Working Voltage	380V/50Hz	Heating Power	1.0 Kw	Noise	≤80dB(A)
Working pressure	5 MPa	Output	1600pair/8h	Net Weight	1135 kg
Machine Dimensions(L*W*H):1710mm×950mm×1950mm
Package dimensions (L*W*H):1760mm×1000mm×2230mm

---
