Counter Top Quartz Slabs Artificial Stone Production Line Counter Top Quartz Slabs

Product Description

Product Description

About Hongfa Automatic Quartz Stone/Slab/Panel production line:
This is an Automatic Quartz Stone/Slab/Panel production line. It produces various specifications and patterns of artificial quartz slab with different colors and designs.
Hongfa arttificial quartz plate production line Quartz Slab Production Line Process:
Slab Making Process: Formula --- Raw Materials Mixing&Stirring --- Raw Materials Paving---Vacuumized Pressing --- Oven Baking ---
Mold Release ---Off line.
Polishing Process: Back Side thickness Calibrating & Sanding---Slab Turnover---Front side Thickness Calibrating----Front Side
Polishing---Edge Trimming---Cleaning& Drying----Printing---Film Coating---Warehousing
Quartz Slab Machinery System:
Raw Materials Mixing &Stirring System
Raw Materials Poving System
Slab Making System
Thickness Calibrating &Polishing System
Quartz Production Line Informations:
Biggest Slab production specifications: 3300mm*1900mm*12-50mm
Main configuration and machine of the quartz stone production line are as follows: 1,Materials mixing system2,Materials distributing system3,Automatic vaccum pressing machine4,Harderning curring oven5,Thicknessing machine6,Polishing machine7,Cutting machine8,Laminating machine,etc.
LX series continuous automatic thickness calibrating machine
LX thickness calibrating machine is designed for the process for calibrate thickness before polishing artificial quartz stone. There are three size- 4 ends, 6 ends, 8 ends. It can process three width type quartz stone: 1m, 1.7m, 1.9m. Range of vertical stroke of the cutter is 60mm, the max thickness of precessable artificial quartz stone is 50mm. LX thickness calibrating machine serves an unique structure- main shaft and guide rail. All part self- lubrication, controlled and displayed by computer. Splash,water and fog proof state is well. Osciallation and transmission speed is adjustable.

Model	Milling head number	Maximum width of the plate(mm)	Maximum thickness of the plate(mm)	Total power(kw)	Dimensions (L*W*H)(MM)	Weight(T)
4L*100	4	1000	50	70	5000*2800*2240	6
4L*170	4	1700	50	70	5000*3500*2240	7
4L*190	4	1900	50	70	5000*3700*2240	8
6L*100	6	1000	50	100	6200*2800*2240	8
6L*170	6	1700	50	100	6200*3500*2240	10
6L*190	6	1900	50	100	6200*3700*2240	11
8L*190	8	1900	50	130	7400*3700*2240	14

LM series continuous automatic grinding machine.
LM series continuos automatic grinding machine is used in process of artificial quartz stone slab. There is 4 / 12 / 16 / 20 heads difference size machine, and there is 1m / 1.7m/ 1.9m most width grinding difference designed. The max lift range of the machine head is 100mm, which allows 50mm thickness of plate at most. The machine have been optimized and upgraded on based on combining domestic and foreign advanced technology, which enhances its lading position in the field. The machine are characterized by its unique structure of its bearing and guide bearing, automatic lubrication, being controlled and displayed by computer, automated detection and alarms reporting system about the situation of plate and abrasive, excellent performance of water and fog resistance, adjustable speed of oscillation and drans mission and being more convenient and safer to replace grinding head.

Model	Grinding head number	Maximum width of the plate(mm)	Maximum thickness of the plate(mm)	Total power(kw)	Dimension (L*W*H)(mm)	Weight
8LM100	8	1000	50	100	7600*2700*2460	9
8LW170	8	1700	50	100	7600*3400*2460	11
8LM190	8	1900	50	100	7600*3600*2460	12
12LM170	12	1700	50	150	9800*3400*2460	15
12LM190	12	1900	50	150	9800*3600*2460	17
16LM170	16	1700	50	200	12200*3730*2460	19
16LM190	16	1900	50	200	12200*3930*2460	23.5
20LM190	20	1900	50	200	1630*3930*2460	32

LY Series Vacuum vibration pressing machine
LY series vacuum vibration pressing machine is used to press bulk material into blank plate, which contains machine frame, vacuum box, vibration motor, lifting oil cylinder, pressurized cylinder, transmission parts, vacuum parts, hydraulic electric control etc. Compare with external type compressor, it has advantages such as low power consumption, light weight, low cost etc.. The machine can make max of 60mm plate thickness, three max width spec. 1000mm, 1700mm, 1900mm.

Model	Maximum width of the plate(mm)	Maximum length of the plate(mm)	Maximum thickness of the plate(mm)	Vibration motor exciting force(kn)	Total power	Dimensions (L*W*H)(mm)	Weight(T)	No.
ZYN100*250	1000	2500	60	32	25	4760*1900*2400	8	6
ZYN100*310	1000	3100	60	32	25	5360*1900*2400	9	6
ZYN170*250	1700	2500	60	50	35	4760*2480*2400	14	6
ZYN170*330	1700	3300	60	50	41	5560*2480*2400	17	8
ZYN190*330	1900	3300	60	50	41	5560*2680*2400	19	8

LQ series artificial quartz stone cutting machine
LQ series cuting machine is used in vertical and holizontal cutting for the plate of quartz stone. It can make the plate pass continuously on the production line and cut down turnover of the plate. There are 4 blade and 5 blade two types according to the different thickness of plate, the plate can be cut to two part. The biggest plate can be cut into 3 sizes, 2500mm, 3100mm, 3300mm and so on, reliable guide rail and spindle structure make sure the incision straigtness, automatic control operational process, computer show data, the length and width can be adjusted within certain limits.

Model	Grinding head number	Maximum thickness of the plate(mm)	Maximum length of the plate(mm)	Conveyor motor power(kw)	Dimension (L*W*H)(mm)
LQ80*250	4	800	2500	7.5	4150*2020*2000
LQ80*310	4	800	3100	7.5	4790*2020*2000
LQ170*330	5	1700	3300	7.5	5000*2920*2000
LQ190*330	5	1900	3300	7.5	5000*3120*2000

LF series plate turnover machine

Model	Maximum width of the plate(mm)	Maximum length of the plate(mm)	Maximum thickness of the plate(mm)	Total power(kw)	Idler wheel out diameter (mm)	Chassis size (L*W*H)mm	Weight(T)
LF100*250	1000	2500	50	1.7	1300	2900*1300	1.5
LF100*310	1000	3100	50	1.7	1300	3500*1300	2
LF170*330	1700	3300	50	1.9	2000	3700*1900	3
LF190*330	1900	3300	50	1.9	2000	3700*2100	3.5

Finished Product & Application
Waht is the raw materials of artificial quartz stone slab?
Raw Materials of Producing the Quartz Stone
The main raw materials to making the Artificial Quartz Stone commonly are: Quartz sand,quartz powder,resin,titanium dioxide and additives. Marble chips,Granite Chips and Glass chips also can be added to make special patterns.
Application of the Quartz Slab
kitchen tops, bathroom vanity top,worktops, laundry,table tops,bench top, bar tops, backsplashes, shower stalls, tub surrounds, wall tile, wall cladding, floor tile, and airport, station, shopping mall, hotel, bank, hospital,etc.
Advantages of the Quartz Stone,Quartz Slab and Quartz Plate
1. Eco-friendly material, non radiation to health, non melamine. 2. Anti bacteria, and chemical resistant, high plasticity, nearly zero water absorption. 3. Easy maintenance; can be renewable after long time using.

Packaging & Shipping
Packing of Artificial Quartz Stone Slab making machinery:
Naked packing or stretch film packing or according to customers' requirements. Suitable for shipping by sea or for long distance road travel when conducting delivery on border.
Company Profile
Hongfa Group since 1990
A leader developer& Manufacturer of Construction Material Machinery
Main business Range & Products:
Lightweight Panel Production Line, AAC Block Production Line, Full Automatic Concrete Block Production Line, Artificial Quartz Plate Production Line, Concrete Pipe Machine, Concrete Tile Machine, Concrete pipe machine, Bidirectional Hydraulic Brick Maker, Mining Machinery, Concrete Batching plant, Stereo Parking Equipment, etc.
Hongfa Strengths
More than 30 years experience. 1500 employee (50+engineers)
2) Total 4 factories with 440,000M2 and annual sell above USD100 Million .
3) 10,000 customers and fulfillment to over 120 countries.
4) Continuous service and logistics system.
5) High quality products and competitive price.We hope we can cooperate with each other and establish a win-win business relationship.
Contact
Do not hesitate to contact with us! Welcome to visit us to see Lightweight Precast Concrete Wall Panel Making Machine, Sandwich Wall Panel Production Line, Fiber Cement Wall Board Machinery running in our factory!
Foreign Trade Dept. : Poppy Jiang 008618031925793
Guangxi Hongfa Heavy Machinery Co., Ltd.
Factory add.: Yilingyan Industrial Zone, Nanning city, Guangxi province, China

---
