Introducing the SLfire 5F EPDM Lined Hose, an extraordinary breakthrough in the realm of fire safety technology! This exceptional hose is engineered with a single jacket, meticulously crafted from high-tenacity polyester filament and spun polyester. It is available in both twill and plain weaves, offering unparalleled durability. At its core, the inner lining boasts robust EPDM material, guaranteeing outstanding performance even in the most demanding conditions.
With superior resistance to ozone, acids, and alkalis, the SLfire 5F is expertly designed to deliver optimal performance, even in the harshest of environments.
Remarkable low-temperature resistance ensures unwavering reliability, even in the chilliest climates. Its extended service life provides lasting protection and peace of mind.
Available in standard lengths of 15M (50 feet), 20M (66 feet), 25M (82 feet), and 30M (100 feet), this versatile hose can be tailored to perfectly meet your unique requirements.
Expertly engineered to withstand temperatures from a chilling -40°F to a sweltering 158°F (-40°C to 70°C), with customizable temperature options available upon your request.
Offered in timeless White, vibrant Red, and eye-catching Yellow, with further color customization available to suit your distinct preferences.
| Inner diameter | Working pressure | Bursting pressure |
| inch | mm | Psi/Bar | Psi/Bar |
| 1" | 25 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 1 1/2" | 40 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 1 3/4" | 45 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 2" | 50 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 2 1/2" | 65 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 2 3/4" | 70 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 3" | 75 | 150/10, 190/13, 220/15, 300/21,400/28,etc | 450/30, 570/39, 660/45, 900/63,1200/84,etc |
| 4" | 102 | 150/10, 190/13, 220/15, 300/21 | 450/30, 600/42, 660/45, 750/51 |
| 6" | 152 | 150/10, 190/13, 220/15, 300/21 | 450/30, 600/42, 660/45, 750/51 |
- Jacket: 100% high tenacity polyester woven reinforcement.
- Lining: Rubber(we can also provide the PVC and TPU and EPDM lining.)
