Factory Good Quality Wet Type Water Tank Wire Drawing Machine

Product Description

Ronen-LT-275 China Factory Good Quality Copper Wire and Steel Wire Wet Type Water Tank Wire Drawing Machine
Company InformationRonen Group is committed to designing and manufacturing of induction heating equipment, which are widely used in machinery,building materials, metallurgy, papermaking, automobile manufacturing and other fields, to fully meet the needs of steel pipe seam welding, stainless steel pipe welding, strip heating, vacuum melting, copper pipe Welding, steel pipe annealing,refrigerator tube welding, metal heat treatment, metal smelting, welding, brazing, thermal assembly and other induction heating process requirements, mainly include spring steel wires, high-strength pipe piles PC steel rods / PC bar, Prestressed steel wire,Prestressed Concrete strand, rebar, aluminum-plastic pipes, wires and cables production equipment lines.Ronen Group domestic market share is more than 60%, and In recent years, we have exported our machines to USA, Europe, Russia, Egypt, Japan, Korea etc. more than 25 countries.Ronen will always be here for you!
General Mechanical SpecificationsFor the Wire Drawing Units Machine framework is welded to form an integral structure, divided into two sections.

It is completely sealed off from dust, front section is installed with transparent organic glass showing the movements of the parts inside during normal operation; the cover is controlled by a safety switch;
Capstan is made of steel plate with spray welding processing,with 80mm height; the working surface has a hardness≥HRC62,life expectancy≥22,000hours

Products parameter

WIRE DRAWING MACHINE
MACHINE MODEL	LT-275	LT-315	LT-380	LTV-120	LTV-200	LTW-200	LTW-250	LTW-300
OUTLET WIRE DIAMETER	0.3-0.5MM	0.3-0.7MM	0.5-0.9MM	0.02-0.05MM	0.06-0.13MM	0.3-0.7MM	0.3-0.8MM	0.3-1.0MM
AVERAGE PASS COMPRESSION RATE	13.3%	13.3%	13.7%	10.63%	12.87% or Customized	13.3%	13.3%	13.3%
SURFACE CONDITION OF TOWER WHEELS	Spraying tungsten carbide	Sprayed tungsten carbide	Sprayed tungsten carbide	Cr12 quenching	Cr12 quenching	Sprayed tungsten carbide	Sprayed tungsten carbide	Sprayed tungsten carbide
SURFACE -HARDNESS OF TOWER WHE	HRC60-6	HRC60-6	HRC60-6	HRC60-6	HRC60-	HRC60	HRC60	HRC60
DRAWING MATERIAL	Medium and high carbon steel wire	Medium and high carbon steel wire	Medium and high carbon steel wire	Medium and high carbon steel wire	Medium and high carbon steel wire	Low, medium and high carbon steel wire	Low, medium and high carbon steel wire	Low, medium and high carbon steel wire
MOLD QUANTITY	17,19,21	17,19,21	17,19,21	17,19,21	25-28	17,19,21	17,19,21	17,19,21
MAX TENSILE STRENGTH	1350MPA	1350MPA	1080MPA	1350MPA	1350MPA	1080MPA	1080MPA	1080MPA
INLET WIRE DIAMETRE	0.8-1.6MM	0.8-2.0MM	2.8MM	0.08-0.2MN	0.6-1MM	0.8-1.6MM	0.8-2.0MM	0.8-2.5MM
