Item
| Specifications
|
Dimension
| 90(L)*70(W)*24(H)mm
|
Weight
| 138g
|
Input Voltage
| 12V-36V
|
Backup Battery
| 700mAh/3.7v
|
Power Consumption
| 60mA standby current
|
GPS Chip
| UBLOX7 Chipset
|
GPS Sensitivity
| -162dBm
|
Channel
| 56 Channel
|
Positioning Accuracy
| 10m
|
4G Frequency
bands
| MT600-A: (North American)
|
| FDD LTE: 700/850/1700/1900MHz
|
| UMTS: 850/1700/1900MHz
|
| GSM: 850/1900MHz
|
|
|
| MT600-E: (Asia/Europe/Australia)
|
| FDD LTE: 800/850/900/1800/2100/2600MHz
|
| UMTS: 850/900/2100MHz
|
| GSM: 850/900/1800/1900MHz
|
|
|
| MT600-C: (Asia)
|
| FDD LTE: 900/1800/2100MHz
|
| TDD LTE: 1900/2300/2500/2600MHz
|
| UMTS: 900/2100MHz
|
| GSM: 900/1800MHz
|
Note: Select proper unit according to local 4G LTE frequency band
| Note: Select proper unit according to local 4G LTE frequency band
|
Hot start
| 1s on average
|
Warm start
| 15s on average
|
Cold start
| 30s on average
|
Working temperature
| -20°C to 70°C
|
Humidity
| 5%~95% non-concretion
|
Antenna
| external 4G/GPS antenna
|
Sensor
| 3D acceleration sensor, temperature sensor
|
LED
| CHG/SYS/GPS
|
SIM Card interface
| Standard SIM
|
Q1. What is the minimum order quantity for your products?A1. Minimum order quantity starts from ONE piece.Q2. What's the quality of your products?A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.Q3. Is this product free of shipping or free samples?A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
