| Panel Type | TFT-LCD | Zoom | 16:9 |
| Best Resolution | 1920×1080 | Color Gamut Color Temperature | 92% 10000K |
| Brightness | 500cd/m² | Weight | 32KG |
| Contrast | 5000:1 | Operating Temperature | 0~60ºC |
| Response Time | 8ms | Working Humidity | 20~80ºC |
| Dot Pitch | 0.1765×0.530mm | Power Supply | 100~240V,50/60HZ |
| Viewing Angle | 178°/178° | Service Life | 60000H |
| Display Color | 8BIT,16.7m | Rated Power Consumption | 180W (Up to 300W) |
| Input Interface | VGA*1,HDMI*1,DVI*1,BNC*2,ISP*1,RS232*1 |
| Output Interface | Control Output RS232*2 |
| Operation Method | RS232 centralized control, network remote control |
| Support Format | NTSC,PAL,480I,480P,720P,1080I |
| Basic Skills | The same unit can display any one of the three types of input signals, the signal type is optional: RGB, VIDEO and component video |
| Continuous Working Time | 24 hours a day, 7 days a week |
| Installation Method (optional) | Wall-mounted, embedded wall-mounted, floor cabinet type, floor stand type |
