US$1,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Main Material
Stainless Steel
Mixing Drum Shape
Conical
Material
SUS304 or SUS316L
Inlet and Outlet
DN25~100
Operating type
Cycle Operating
Transport Package
Playwood Cases
Specification
0.5T/H ~150T/H
Production Capacity
100 Set/Month
Product Description
SUS304 stainless steel sanitary inline emulsifier mixer
1.SUS304 stainless steel sanitary inline emulsifier mixer can process large quantity of material with various viscosity, very suitable for industry online production.
2.It has the character of better emulsification and better efficiency.In complete range of articles,to meet the different processing option. 3.There are different kind of stainless steel lik 304,316L for different PH requirement. 4.Adopting double mechanical seal,also can match up the water protector. 5.SUS304 stainless steel sanitary Homogenizer pump emulsifying pump has many kind of connection like rigid connection,flexible connection,etc.
| Profile type | Best price high performance vacuum mixing pumps cosmetics |
| material | SS304 or SS316L |
| Capacity | 0-130T (Customized) |
| pressure | 0-2Bar |
| Viscosity | 1-1000000pas |
| rotors teeth | Fine/Middle/rough |
| temperature | 0-100 celsius degree |
| installation | Movebale or Fixed |
| connection | Clamp union flange |
| motor type | Normal | Ex-proof | inverter |
| Speed | 0-3400RPM |
| Model | L2(mm) | L(mm) | H(mm) | A(mm) | H2(mm) | H3(mm) | DΦ(mm) | BΦ |
| RAY-1-80 | 74 | 528 | 367 | 240 | 180 | 126.5 | 38 | 32 |
| RAY-1-100 | 74 | 528 | 367 | 240 | 180 | 126.5 | 38 | 32 |
| RAY-1-130 | 76 | 611 | 413 | 290 | 202 | 135 | 51 | 38 |
| RAY-1-140 | 80 | 660 | 490 | 340 | 222 | 152.5 | 63.5 | 51 |
| RAY-1-165 | 80 | 700 | 490 | 340 | 222 | 152.5 | 63.5 | 51 |
| RAY-1-180 | 92 | 847 | 554 | 382 | 260 | 167.5 | 63.5 | 63.5 |
| RAY-1-185 | 92 | 847 | 554 | 382 | 260 | 167.5 | 76.2 | 63.5 |
| RAY-1-200 | 96.5 | 957 | 585 | 410 | 290 | 181 | 76.2 | 63.5 |
| RAY-1-210 | 109 | 1035 | 659 | 460 | 310 | 186 | 89 | 76.2 |
| RAY-1-230 | 115 | 1090 | 705 | 460 | 323 | 196 | 102 | 89 |
| RAY-1-245 | 132 | 1160 | 750 | 570 | 370 | 204 | 102 | 102 |
| Technical Parameters |
| Model | capacity (T/H) | Speed(RPM) | out Pressure(bar) | power(KW) |
| RAY-1-80 | 0-1.5 | 2900/3400 | ≤2Bar | 1.5 |
| RAY-1-100 | 0-3 | 2900/3400 | 2.2 |
| RAY-1-130 | 0-4 | 2900/3400 | 4.0 |
| RAY-1-140 | 0-5 | 2900/3400 | 5.5 |
| RAY-1-165 | 0-8 | 2900/3400
| 7.5 |
| RAY-1-180 | 0-12 | 2900/3400 | 11 |
| RAY-1-185 | 0-18 | 2900/3400 | 15 |
| RAY-1-200 | 0-25 | 2900/3400 | 22 |
| RAY-1-210 | 0-35 | 2900/3400 | 30 |
| RAY-1-230 | 0-50 | 1450/1700 | 45 |
| RAY-1-245 | 0-75 | 1450/1700 | 55 |
| We can customize the equipment according to customer requirements. |
| 1.Q: Are you manufacturer or trading company? |
| A: RAYEN is a professional manufacturer. |
| 2.Q: How could we confirm the details of the products? |
| A: RAYEN will provide the detail drawings for you to confirm. |
| 3.Q: How long the warranty will be? |
| A: 1 Year warranty. |
| 4.Q: Do you take L/C? |
| A: Yes, we accept Western Union, T/T and irrevocable L/C payable |
| 5.Q: Can we become your distributor in our country? |
| A: Yes, we very welcome you! More details will be discussed if you are interested in being our agent. |
>>
