| US$2,000.00-4,800.00 | 1 Piece (MOQ) |
| Model | 20 |
| Opreration weight | 1490kg |
| Engine | Yanmar |
| Power | 10.3kw |
| Bucket capacity | 0.05CBM |
| Rotation speed | 9r/Min |
| Overall dimension | 3250mmX1100mmX2300mm |
| Crawler grounding length | 1300mm |
| Crawler weidth | 180mm |
| Max digging height | 3200mm |
| Max discharge height | 2300mm |
| Max digging depth | 2200mm |
| Max digging radius | 3360mm |
| Mini turning radius | 1350mm |
| Platform clearance to ground | 370mm |
| Swing angle | 360° |
| Climbing gradient | 30° |
| Bulldozer Max depth | 190mm |
| Bulldozer Max raising height | 260mm |
| Walking speed | 0-3km/h |
| Bucket digging force | 16.5KN |
| Hydraulic system press | 160MPa |
| Bucket width | 430mm |
| Remark | Simple shed,can add cab |
| Base plate | Working device | cab | Engine type | Dynamic performance | |
| The chassis design of small excavators is relatively compact, and most of them use track type or tire type. Tracked chassis can provide better stability and traction, suitable for a variety of complex terrain, such as muddy work sites, soft soil, etc. The wheeled chassis has higher maneuverability and moves faster on flatter roads, making it suitable for short-distance transfers in environments such as urban roads. | The structural strength of the boom and bucket rod can meet the needs of small excavation tasks. The hydraulic system can precisely control the action of the working device to achieve flexible digging Angle and depth. For example, when digging a pipe, the operator can control the hydraulic system so that the bucket can dig at the right Angle to avoid damaging the underground pipe. | Buckets are also available in a variety of shapes and sizes. There are sharp-toothed buckets for digging hard soil, and flat-mouth buckets for loading loose materials | The cab design of small excavators pays attention to comfort and operability. Although the interior space is relatively small, the layout is reasonable, and the seats can be adjusted to facilitate the use of operators of different sizes. The ergonomic placement of the handle and instrument panel allows the operator to easily operate a variety of control buttons and joysticks. The cab of some high-end small excavators is also equipped with air conditioning, radio and other equipment to improve the working comfort of the operator. | Small excavators generally use diesel engines or electric engines. The diesel engine has a high torque and power output, which can adapt to more heavy excavation work. And diesel engine fuel storage is relatively convenient, do not need frequent refueling. Electric engines have the advantages of environmental protection and low noise, and are suitable for use in urban environments or indoor places with high noise and emission requirements. | The engine power of small excavators is usually between 10-50 kW, and this power range can meet the needs of excavation, loading and other operations in small projects. For example, in a small garden renovation project, its power is enough to dig flower beds, carry flower soil, etc. |
| Energy-saving and efficient | Small excavator engine power is small, fuel consumption is relatively low, in the operation process can effectively reduce energy consumption, save the use of costs. At the same time, its work efficiency is high, and it can complete a lot of work in a short time. |
| Low maintenance cost | The structure is relatively simple, the number of parts is small, and the daily maintenance and maintenance work is easier, reducing the maintenance cost and downtime. |
| High security | It is usually equipped with perfect safety devices, such as emergency brake button, safety belt, protective fence, etc., to ensure the safety of the operator. In addition, because of its better field of view when working in small Spaces, operators can better observe the surrounding environment and reduce the occurrence of safety accidents. |
| 1. How long is the delivery time? According to your size and system, the delivery time is usually 15-60days. 2. Can you supply sample? Small parts can be supplied, but you should pay the express cost. 3. Can your company supply design? Our company can give g design according to your land and plan after deposit. And we can give simple drawing before signing contract. 4. How to install ? Firstly we prepare the material and send the material to your city. After your customs clearing, we send 2-4 engineers or all workers to guide to install. If you want to save money, we only send engineers, and you match local workers. If you think it is hard to build the greenhouse, we also can send engineers and workers to install for you. 5. When installing, what cost should we pay? Our engineers and workers visas and round-trip tickets, their foods and accommodation, their communication |
