US$9,000.00-12,000.00
|
1 Set
(MOQ)
|
Basic Info.
Shape
Half Circle/Circle/Square/Hexagon/Capsule
Control Mode
Effective Vector Vvvf Frequency Invert
Elevator Door
Automatic or Manual
Certification
ISO/CE/Bl/TUV/SGS
Control System
Step As380 or Monarch Nice3000 New
Cabin Material
Glass, Hairline Stainless Steel, Golden Etched,etc
Shaft
Concrete or Steel Structure
Optional Function
Ard, IC Card, Remote Monitor
Position Indicator
DOT Matrix Display, LCD
Motor
Xizi, Torin, Mona, Faxi
Door Brand
Nbsl, Ouling, Fermator
Cop&Lop
Stainless Steel, Glass
Transport Package
Standard Export Package
Trademark
OTSTEC/Customize
Production Capacity
3000 Sets/Year
Product Description
Product Description
Product Parameters
Small Machine Room |
Loading Passenger | Loading Capacity | Speed | Car Size | Shaft(Min.) | Overhead Height | Rise(Max.) |
Passenger | (Kg) | (m/s) | W*D*H(mm) | W*D(mm) | W*D(mm) | HQ(Max.)(m) |
6 | 450 | 1.0 | 1100*1100*2400 | 1700*1800 | 4500 | 45 |
8 | 630 | 1.0-1.75 | 1400*1100*2400 | 2000*1800 | 4500 | 95 |
10 | 800 | 1.0-2.5 | 1400*1300*2400 | 2000*2000 | 4500 | 120 |
13 | 1000 | 1.0-3.0 | 1600*1500*2400 | 2200*2200 | 4500 | 150 |
16 | 1250 | 1.0-4.0 | 1950*1400*2400 | 2600*2100 | 4500 | 180 |
21 | 1600 | 1.0-4.0 | 1950*1750*2400 | 2600*2450 | 4500 | 180 |
Machine Room less |
Loading Passenger | Loading Capacity | Speed | Car Size | Shaft(Min.) | Overhead Height | Rise(Max.) |
Passenger | (Kg) | (m/s) | W*D*H(mm) | W*D(mm) | W*D(mm) | HQ(Max.)(m) |
6 | 450 | 1.0 | 1100*1100*2400 | 1900*1500 | 4500 | 45 |
8 | 630 | 1.0-1.75 | 1400*1100*2400 | 2200*1500 | 4500 | 95 |
10 | 800 | 1.0-2.5 | 1400*1300*2400 | 2200*1700 | 4500 | 120 |
13 | 1000 | 1.0-2.5 | 1600*1500*2400 | 2400*1900 | 4500 | 150 |
16 | 1250 | 1.0-2.5 | 1950*1400*2400 | 2750*1800 | 4500 | 180 |
21 | 1600 | 1.0-2.5 | 1950*1750*2400 | 2750*2150 | 4500 | 180 |
1. Material: Painted, Hairline stainless steel, mirror, etched, Titanium gold, rose gold, golden recess, glass;
2. Capacity: 250KG, 320kg, 400kg;
3. Speed: 0.4m/s,1.0m/s,1.5m/s, 1.75m/s,2.0m/s
4. Type: Traction home elevator, Strong drive home elevator, Steel belt home elevator, Knapsack frame structure home elevator;
5. Machine Room: Machine Roomless (MRL)
6. Control system: Monarch
Production Process
Packaging & Shipping
Certifications
Exhibitions
Our Advantages
FAQ
Q1. What is your terms of packing? A: Generally, we packed our goods by solid wood case, If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters. Q2. What is your terms of delivery? A: EXW, FOB, CFR, CIF. Q3. How about your delivery time? A: Generally, it will take 25 to 30 days after you confirm the elevator (escalator) specification and drawing, and receiving your advance payment. Q4. Do you test all your goods before delivery? A: Yes, for elevator,we will assemble the cabin,cabin frame,door operator ,for escalator,we will test to run 72 hours before delivery,at the meanwhile,we will send you many test pictures. Q5: How do you make our business long-term and good relationship? A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
>>
