High Efficiency Wood Crusher Hammer Mill Grinding Machine/Large Capacity Drum Type Wood Chipper/Waste Wood Crusher Wood Chipper

Product Description

High Efficiency Wood Crusher Hammer Mill Grinding Machine/Large Capacity Drum Type Wood Chipper/waste wood crusher
Product Description
The wood crusher machine, also known as the wood sawdust machine, integrates slicing and crushing. It can cut branches and logs with a chip diameter of 1 to 45 cm. It can also be used to crush fibrous stalk-like materials such as wood,bamboo, Alfalfa, Peanut Shell, Straw, thatch, corn stalks, and sorghum stalks. This machine has a wide range of uses, low price, and very stable quality, so it sells very well in the foreign trade market.
Product Parameters
Wood Crusher Machine

Model	Power(kw)	Capacity(kg/h)	Remark
Model 500 double port crusher	15 30	300-500/kg/h 600-1000kg/h	Log 15cm, plate 35cm
MT600model double port crusher	22/37/45	700-800kg/h 1000-1500kg/h 1500-1800kg/h	All crusher include parts: electric control cabinet, dust removal, chakroun, air damper
MT800 model double port crusher	45	2000-2200kg/h
MT1000 model double port crusher	72	2500-3000kg/h
MT1300 model crusher	132	4ton-5ton/h

Self-Forced Feed Wood Crusher

Model	Capacity	Size	Power
500Heavy with forced feed conveyor belt	1000-1200	5.3/1.5/1.6	30+3+1.5
600Heavy with forced feed conveyor belt	1200-1500	5.45/1.6/1.7	37+3+1.5
800Heavy with forced feed conveyor belt	2000-2500	5.6/1.4/1.8	45/55+3+1.5
1000Heavy with forced feed conveyor belt	3000-3500	6.2*2.4*1.68	75+4+1.5+11
1300 1000Heavy with forced feed conveyor belt	4000-5000	6.5*4*4.5	132kw

Integrated Chipper crusher

Model	Capacity	Equip include	Power
600 Integrated Chipper crusher	4-5t/h	Feeding and discharging conveyor, control cabinet, oil pump, remote controller	55kw
1000 Integrated crusher	5-8t/h		90kw
1300 Integrated crusher	10-15t/h		132kw

Detailed Photos
Application field
The wood crusher is used to crush wood log, branches, or wooden crops waste such as straw, palm leaves, corncob, and other branches. The output sawdust size can be controlled by the sieve inside. The final outputs can be used for making pellets, organic fertilizer, feed, mushroom substrate or charcoal rod.
Working principle
Wood flour machine structure and crushing principle:1. The wood flour machine is composed of three parts: the body, the middle body and the lower body.2. The crushing knife is composed of a 7-type knife, a 1-type knife and a centrifugal knife.3. The auxiliary machine is composed of a fan, a powder collector and a dust collector.4. The main machine's crushing chamber adopts 7-type knife, one-type knife and centrifugal knife. There are coarse crushing, fine crushing and centrifugal reciprocating crushing. The motor drives the rotor of the crusher to run at high speed, so that the machine generates high-speed airflow to produce high-strength crushing materials. Impact force, compression force, cutting force, friction force, to achieve a unique crushing function.5. During the cutting and crushing process of the three kinds of blades, the rotor generates a high-speed airflow that rotates with the direction of the blades. The materials are accelerated in the airflow and repeatedly impacted and cut friction. At the same time, they are subjected to three kinds of crushing effects. The crushed materials enter the analyzer with the airflow. Analysis, due to the centripetal force of the airflow when it is subjected to the centrifugal force of the analyzer rotor, when the centrifugal force is greater than the centripetal force, the fine particles will enter the powder collector with the airflow for collection, and the coarse particles will enter the centrifugal crushing chamber and continue to be crushed until you are satisfied. The fineness.
Packaging & Shipping
Our Advantages
1.Easy to transport
wood crusher with high chassis plate, short wheel base, and turning radius,making them very easy to drive, especially in transport to hard to reach.
2.Greatly reduce material transportation cost
wood crusher can be directly transported to the raw material to be processed at the reduced mass transportation of raw materials sectors, thus saving the cost of transportation of raw materials.
3.Wide range of uses
wood crusher can be operated as independent units, two-stage crushing plant with primary and secondary crushing, three-stage crushing plant with primary, secondary, and tertiary crushing.
4.Good performance and easy to maintenance
wood crusher adapt excellent quality crusher, belt conveyor can be used to deliver normal materials, stable and reliable performance, simple operation, easy maintenance, low investment and high return.
Pre-sales service 1.Tailor-made efficient technical solutions for you. 2.Tell us your needs, we will recommend the machine to you, professionally introduce the machine 3.Service consultation in 365 days a year. 4.24 hours to respond to messages in a timely manner service During the project 1.Standardized precision production of production orders in 8 major departments. 2. The operation of the machine will be tested before delivery, video will be given to the customer, and the machine will be checked and accepted 3.The entire production process is visualized, which is convenient to check the production progress at any time. 4.The idling machine test is combined with the feeder test - strict quality inspection. After-sale service 1. Accepting service consultation in 365 days a year. 2. Our after-sales engineer can come at any time for maintenance. 3. We will return customers on a regular basis, to ensure proper operation of the production line. 4. We provide accessories for all equipment.
FAQ: Q: What are your payment terms?
A: 50% deposit by T/T, balance to be paid before shipment.
Q: What are your main markets?
A: Southeast Asia, Africa, Oceania and Europe
Q: What is your production time?
A: The production time depends on the machine you order. It usually takes 45 days.
Q: What documents can you provide?
A: We can provide invoices, packing lists, contracts, instructions, customs declarations, certificates of origin, CE. If the customer needs other documents and specifications, please confirm with the service staff.
Q: How will you deal with quality problems in the equipment?
A: We will be responsible for all quality problems. We'll check the machine to find out the problem. If you need parts, I'll send them to you.
Q: How long is the warranty?
A:One year.(Damage to vulnerable parts is not guaranteed and requires additional purchase)

---
