Mini Trailer for Mini Tiller with 500kg Loading Capacity

Negotiable 165 Pieces (MOQ)

Basic Info.

Model NO.
7C-0.5C
Certification
CCC, ISO
Structure
Dump Trailer
Air Brake Type
Air Inflating
Axle Number
1
Nosewheel Steering Mechanism
Wheel Steering
Dumping Direction
Backward
Tire Number
2
Condition
New
Transport Package
in Loose Packing
Specification
box 1.4m*1m
Trademark
wolong
Origin
Weifang
HS Code
8716200000
Production Capacity
40, 000 Units Per Year

Product Description


1) box size 1.4m*1m.
2) box in loose packing.
3) strong axle.
4) color customized.
1) loading capacity: 500kg
2) for 4hp-8hp mini tiller(walking tractor)
3) with brake
4) easily assembled.
Overall dimension(mm) 3010*1600*1000
Carriage dimension(mm) 1400*1000*300
Seat dimension(mm) 400*240*50
Matched tire 4.00-10 or 4.50-12
Net weight(kg) 134kg
Load capacity(kg) 500kg
Max. load capacity(kg) 750kg
Brake type Mechanical type
Angle of Inclination > 45°
Height of loading surface 490mm
Quantity/40HQ 140 units
