| Description | 2.4g&5.8g AX3000 wifi 6 NSA SA sim card router 5g |
| Item no. | HY801 |
| CPU | MT7621AT+SDX55 |
| Flash | 16MB |
| RAM | 2Gb |
| Sim slot | Nano-SIM |
| WiFi Frequency | 2.4G&5G |
| WiFi Standard | 2.4G:802.11b/g/n /ax 2T2R MIMO, 5.8GHz：802.11a/n/ac/ax 2T2R MIMO |
| WiFi | 2.4GHz :600Mbps ,5GHz :1200Mbps |
| 5G Standard | 3GPP Release 15 NSA/SA operation, Sub-6 GHz |
| 5G Network Mode | NSA/SA |
| 5G/4G Data Rate | 5G SA Transmission Speed: 2.1Gbps/900Mbps (up to ISPs) 5G NSA Transmission Speed: 2.5Gbps/650Mbps (up to ISPs) LTE: Down 1.0 Gbps; UP 200 Mbps |
| 5G Frequency | 5G NR NSA n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79 5G NR SA n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79 |
| LTE Category | Down Cat 16/UP Cat 18 |
| 4G&3G Frequency | FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 TDD: B34/B38/B39/B40/B41/B42/B43/B48 4×4MIMO:B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66 WCDMA:B1/B2/B3/B4/B5/B8/B19 |
| Wifi receive sensitivity | 2.4G: 11X HE20: -70dBm@MCS11, -80dBm@MCS0. 11X HE40: -70dBm@MCS11, -80dBm@MCS0. 11n HT20: -70dBm@MCS7, -80dBm@MCS0. 11n HT40: -70dBm@MCS7, -78dBm@MCS0. 11g: -68dBm@54Mbps, -82dBm@6Mbps. 11b: -70dBm@11Mbps, -85dBm@1Mbps. 5.8G: 11a: -72dBm@54Mbps, -85dBm@6Mbps. 11nHT20: -75dBm@MCS7,-85dBm@MCS0. 11nHT40: -75dBm@MCS7,-88dBm@MCS0 11ac HT80: -65dBm@MCS9 11aX HT80: -65dBm@MCS11 |
| EVM | 802.11n@MCS7: ≤ -30dB 802.11g@54M: ≤ -30dB 802.11b@11M: ≤ -15dB 802.11a@54M: ≤ -28dB 802.11ac @MCS9: ≤ -33dB 802.11aX @MCS11: ≤ -33dB |
| Frequency Deviation | ±20ppm |
| Interface | 2*10/100M/1000 LAN 1*10/100M/1000 WAN 1*12V 2A DC Power Input 1 Reset Button 1 Breathing Light Button 1 SIM card slot 1 MESH Networking Button |
| Network Extension | MESH |
| Reset | Reset（Long press 10 seconds to restore the factory settings） |
| MESH | Networking: short press (blue networking light flashes) |
| LED Indicator | Power, Breathing Light, 4G Signal, 5G Signal, WiFi Signal |
| Power Consumption | ＜24W |
| IPV4 | Support |
| IPV6 | Support |
| Smart QOS | Support |
| Parent Control | Support |
| UPNP | Support |
| VPN | Supports L2TP VPN client; Supports PPTP VPN client |
| APN | Support |
| DDNS | Support |
| DMZ | Support |
| Port Mapping | Support |
| MESH | Support |
| APP | Support |
| TR069 | Support |
| WiFi Encryption | Open WEP WPA2-PSK WiFi Encryption WPA3-SAE WPA/WPA2-PSK WPA2-PSK/WPA3-SAE |
| Operating Environment | Operating Temperature:Normal:0°C to +45°C; Operating Temperature:-20° C to +70° C Operating Humidity:5%~ 95% Storage Humidity:5%~ 95% |
| Dimension | Device: 130*140*300MM |
| 15pcs/ctn size: 660*440*320mm G.W.: 20Kg/ctn | |
| Package | 1m Cat 6 Ethernet cable*1pc, Power Adapter*1pc, Quick Start Guide*1pc,5G CPE Router*1pc |
