Lcng High Pressure Filling Pump (TV-2000/250)

US$1,000.00-5,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
TV-2000/250
Pressure Medium
Cryogenic Liquid Gas
Type
Handheld
Position of Pump Shaft
Horizontal
Certification
ISO
Hs
8413810090
Transport Package
Carton/Plywood
Specification
CE GS
Trademark
Toplong compressors
Origin
China
HS Code
8413810090
Production Capacity
10000PCS/Month

Product Description

LCNG high-pressure pump (three)
For media
Liquefied natural gas (LNG)
Range
LNG filling stations
The main technical parameters
Flow: 1200-3000 L / h
Maximum outlet pressure: 25 Mpa
Optional
Inverter
Explosion overpressure interlock device
Safety valve, temperature valve (into the liquid, return air and deflated)
High-pressure emergency shut-off vent valve (pneumatic)
Outlet temperature interlock device
Pump temperature interlock device (to prevent cavitation)
Leak detection and alarm devices
Features
All electrical components required configuration by explosion
High vacuum jacketed cold end, only the cold side outside diameter 105mm, minimize cold loss
Design pressure 35Mpa, downgrade safety factor
Three-piston, outlet pressure pulse small, smooth motor load
Gearbox lubrication system using an independent, stable, long bearing life
Low Noise
Optional helium blowing system, can greatly reduce the trace gas leak potential safety problems
Model Type Flow Range L/h Inlet Pressure Mpa
Max Pressure Mpa
TV-1500/250
TV-2000/250
TV-2500/250
TV-3000/250
Single
Triple
Piston
1500
2000
2500
3000
0.02-1.6 25.0
