Cardboard Box Forming Machine for Hamburger

Product Description

Cardboard Box Forming Machine for Hamburger:
It is an ideal equipment to produce paper box such like hamburger box, chips box. Fried chicken box, kids meal box, etc.
Automatic Carton Erecting Machine with firm structure, high quality, low noise and high efficiency.
It has paper feeding unit, adjusted unit, glue unit, forming unit, finished products collecting unit and also counting unit.
Technical specifications:
1. Box length L 100-450mm and angle: 5° -40°
Box width B 100-580/385mm and cardboard weight: 200G/M2-600g/ m2
Edge height H 15-200mm and corrugated paper thickness: 1.5mm

	HBJ-D800	HBJ-D1200
Productivity	60-160pcs/min	120-300pcs/min
Material	200-600gsm	200-600gsm
Power Source	380V50Hz	380V50Hz
Total Power	5.5KW	5.5KW
Box Length	100-450mm	100-450mm
Box Width	100-600mm	100-385mm
Packing Size	3600*1500*1700mm	3600*1850*1700mm
Weight	2.2T	2.8T

Carton Erecting Machine(single head)
The paper box made by this machine can be used in packing of KFC and Mcdonald. S or other
Erecting Machine(single head) Hamburger Press printing machine
Carton Erecting Machine(single head)
The paper box made by this machine can be used in packing of KFC and Mcdonald s or other food
2. Work principle:
The feeder transmits the pre-printed and cut cardboard from the paper shelf to the convey chain and the sends it to the shaping mold, during the procedure, the cardboard has been glued an you can adjust the position of the gluing, the volume of gluing can be measured while in progress withour stopping word. After being glued, the cardboard will be conveyed to be shaped and collected to be auto calculated as the preconcert quantity and auto mark withouot stopping production, structure: Control unit, paper feeding unit, paper transfer unit, glue spreading unit, forming unit, collecting unit.
Our Service:
1.Spare parts guarantee for one year in machine arrival.
2.Send the technician for installation & training.
3.Offer Service Online
FAQ:
1.Q:Are your company a manufacturer or trading company?
A:We are a manufacturer with ten years of exporting experience by own trading company

2.Q:Where is your factory? How can I get there?
A:Our factory is located in wenzhou City, Zhejiang Province. It takes about one and a half hours by train from Shanghai to our city. all of our customers can take the flight to wenzhou international airport first, and then we can send a car to pick up you.

3.Q:Can your products be customized?
A: Almost all of our products can be customized, including the sizes, color, logo, package and so on. OEM orders are highly welcome.

4.Q . how's the delivery time ?
A. Usually it will take about 3-4 weeks for production,all of our machinery shall be packed well with film to be water proof, and then loading and fix in a wooden case
If you are interesting in our machine,please feel free to contract with us:
Mobile:+86 13819753964

Website:daqiao3066.en.made-in-china.com

---
