US$450,000.00-550,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Plastic Type
Thermoplastic
Certification
CE, ISO9001:2008
Function
Plastic Injection Molding Machinery
Key Selling Points
Flexible Manufacturing
Machinery Test Report
Provided
Keyword
Car Bumper Injection Molding Machine
Motor
Servo Energy Saving Motor
Showroom Location
Egypt, Turkey, United Kingdom, United States, Fran
Plasticizing Capacity(G/S)
204G
Injection Rate (G/S)
1634 G/S
Ejector Stroke(mm)
450 mm
Video Outgoing-Inspection
Provided
Plastic Processed
PP, PC, ABS, Pet, PVC, PPR, EVA, HDPE, PE, LDPE
Transport Package
Fixed in The Container with Wire Rope, Suitable Fo
Specification
CE standard
Production Capacity
5000sets/Year
Product Description
Powerjet plastic chairs and tables making machines moulding injection molding machine for plastic chair
Two-Platen Injection Molding Machine
DP Series Two-Platen Large Injection Molding Machine For Deep Cavity Products Like: Home Appliances, Car Parts, Outdoor Dustbin, Plastic Pallet, Plastic Crate etc.
FEATURES:
1:Saving More Space - Small footprint, bigger mold carrying capacity.
2:Saving More Power - Servo system configuration, more energy-saving ability.
3:High Precision - Less production flash.
4:Lower Noise - Small hydraulic impact, lower noise and oil consumption.
5:More Automation - Accurate mold positioning meets the needs of automatic pickup and insert.
6:Longer Lifetime - Even mold force insures long service life.
7:High Rigidity Slider - With better orientation and parallelism, can carry heavier molds.
8:Step-less Adjustment - Ensures the accurate and stable clamping force.
9:High Rigidity Clamping Frame - Makes the whole machine running more smoothly.
10:High Precision Linear Guide - Faster injection response and accurate positioning.
11:Variety Of Screw Available - Adapts to different types of products.
12:Higher Standard Configuration - With 12" colorful display screen, CPU memory upgrade to 1.4G.
Product Parameters
DESCRIPION | | UNIT | DP2100-S6 |
CLAMPING UNIT
| Clamping force
| KN
| 21000
|
Opening stroke
| mm
| 3050/2050
|
Max.daylight
| mm
| 3750
|
Space between bars
| mm
| 1800*1600
|
Max.mold height
| mm
| 1700
|
Min.mold height
| mm
| 700
|
Ejector stroke
| mm
| 400
|
Ejector force
| KN
| 350
|
INJECTION UNIT
| Screw diameter
| mm
| 150
|
Screw L/D Ratio
| L/D
| 22
|
Injection Pressure
| MPa
| 156
|
Shot volume
| cm3
| 14579
|
Shot weight (ps)
| g
| 13266
|
oz
| 468
|
Injection rate
| g/s
| 1556
|
Plasticizing capacity
| g/s
| 290
|
Screw stroke
| mm
| 825
|
Screw speed
| rpm
| 80 |
POWER UNIT
| Hydraulic system Pressure
| MPa
| 17.5
|
Pump motor power
| KW
| 2*57+54
|
Heater power
| KW
| 107
|
GENERAL
| Oil tank capacity
| L
| 1800
|
Machine weight
| T
| 95
|
Machine dimensions (L*W*H)
| m
| 14.9*4.5*3.5
|
Company Profile
Powerjet Plastic Machinery Co., LTD Focus On Manufacturing And Development Of Injection Molding Machine And Blow Molding Machine Over 20 Years. Powerjet And Installed Over 18,500 Molding Machines Worldwide And Renowned In "Energy-Saving, High Performance,High Speed,Precision".Factory in 50,000 square meters, with more than 350 staff members, over 20 branch offices across the country with the advanced experience and lean production.
And we also focuse on the development of special injection molding machines according to the customer's need, like machines for PET preform,PVC/PPR fitting, thin-walled product, sillicone,batelite,and multi-material products, and also provide the turnkey projects for the customers.
Our Services & Strength Established distributors in multiple countries like Thailand, Malaysia, Indonesia, Vietnam, Uzbekistan, USA, Mexico, Brazil, and Pakistan. With global sales network, our local offies and agents can provide more convenient and sincere services. 1:Agent In Worldwide
Setting Up Agent In More Than 20 Countries For Sales And Support
2:Lifetime Support
24 Hours Online Service And Overseas Installation & Maintenance
3:Spare Parts
We Supplying Screw, Motor, Control Panel And Plastic Mold For Machines
4:Operation Training
Support Training To Engineer For Setup, Processing & Troubleshooting
5:Plastic Mold Testing
Provide Testing Mold Service Before Customer Receiving The Machine
FAQ
Q1: Are you a manufacturer or trading company?
A1: We are a factory for plastic machines. Over 23 Years Experience In Manufacturing Injection Molding Machine And Blow Molding Machine.
Q2: Delivery time?
A2: Normally Machine Delivery from the factory in 0-60 days after receiving the down payment. (During Chinese Public Holidays like National Day or Chinese New Year, the delivery time should be 10-30 days longer accordingly).
Q3: Where is your factory located?
A3: Our factory is located at No.5 Chuangxin Xi Road, Leping Town, Sanshui District, Foshan City, Guangdong Province, China. 1h drive from Guangzhou to our factory. Welcome to visit our factory.
>>
