High pressure Force feeding briquetting machine with CE certificate:
High pressure briquetting machine adopt the screw governor pressure, high hydraulic forces squeeze the second compression molding. It features in high pressure and strong strength of briquette, and widely used in metallurgical, chemical, and refractories industry, etc. Applicable to limestone powder, magnesium oxide powder, copper powder, chromium powder, lead, zinc scrap, bauxite, nonferrous metal powders, coal, charcoal powder, aluminium, refractory, ceramic materials, etc.
|
| SPECIFICATIONS FOR FORCE FEEDING HIGH PRESSURE BRIQUETTE MACHINE
|
|
|
Model
| Roller Dia.
(mm)
| Roller Width (mm)
| Total Pressure (t)
| Main Power(kw)
| Pre-press Power(kw)
| Hydraulic Pump Power
(kw)
| Capacity(t/h)
|
QYQ-476-1
| Φ476
| 196
| 95
| 45
| 15
| 1.5
| 1-3
|
QYQ-476-2
| Φ476
| 210
| 95
| 55
| 15
| 1.5
| 2-4
|
QYQ-520
| Φ520
| 196
| 95
| 55
| 15
| 1.5
| 3-5
|
QYQ-650
| Φ650
| 196
| 100
| 75
| 18.5
| 1.5
| 4-6
|
QYQ-672
| Φ672
| 275
| 100
| 75
| 22
| 2.2
| 6-10
|
QYQ-750
| Φ750
| 196
| 120
| 110
| 22
| 2.2
| 5-8
|
QYQ-850
| Φ850
| 196
| 120
| 132
| 22
| 2.2
| 6-10
|
Main Features
-Good price with CE ISO certificate.
-Forcee feeding high pressure type briquette machine
-Strong structure,high briquetting ratio because the briquette machine excellent design
-It can be the single machine or whole production line.
-Roller material can be 65Mn, 9Cr2Mo, Alloy Steel, -high-chromium alloy and so on
-Final product size 25-70mm and shape can be round,pillow&square shape.
-Engineer available for installation in customer country for briquette machine.
-Provide the matched binder for the briquettes making.
-Engineer available for installation in customer country.
Certifications
Our briquette machine's ISO and CE certificate has been approval
Detailed Images
Machine Parts
Name: Roller.
Roller material can be 65Mn, 9Cr2Mo, Alloy Steel, -high-chromium alloy and so on
The final product shape and the size can be design according to you,also,our engineer will suggest you the best size and shape for you.
Main Features
Name: Screw feeding parts
It can supply a pre-pressure to the raw materials, the force feeding device ensures the evenly feeding and more bigger pressure.
Machine hydraulic pump
Hydraulic pump is the essential part of the hydraulic briquette machine, it provide hydraulic force to the roller and make sure the final briquettes is strong and hard.
Main Features
Every detail part is fine workmanship, to ensure the machine's better usage and running.
Our Service
Pre-Sales Service.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Company information
Gongyi Hengchang Metallurgy Building Material Equipments plant was built in 1992, is a professional manufacturer specializing in the production of mineral beneficiation equipments, sand and stone crushing equipments, briquetting equipments, coal preparation equipments, drying and calcining equipments, cement plant equipments and compound fertilizer equipments. The products are widely used in mineral processing, metallurgy, building materials, chemicals, electricity, petroleum, coal, transportation, fertilizer , gas industry etc.
FAQ
Questions to the buyers.
1. What's the raw material there?
2. What's the raw material size and moisture? For briquetting, the size should be less than 5mm, moisture 10-15%
3. What's the capacity you want to process?
4. What's the final briquettes' shape and size you would like?
5. Do you need a complete production line equipment? Or just a single briquette machine?
