CE Approved Standard Auto Car Lift 2 Post Car Lift

US$1,500.00 1 Set (MOQ)

Basic Info.

Model NO.
SY-232B
Type
Double Cylinder Hydraulic Lift
Lifting Capacity
3T
Driving Type
Hydraulic
Certification
CE
Driving Motor Number of Mechanical Lift
1
Double Cylinder Lift Type
Planer-type
Shearing Lift Type
Small Shear Type
Condition
New
Brand
Shinely
Design
Two Post
Color
as Require
Voltage
as Require
Transport Package
Polyfoam and Carton
Specification
CE ISO9001: 2000
Trademark
BZB
Origin
Guangzhou, China
HS Code
84198990
Production Capacity
500sets/Year

Product Description

SY-232B two post hydraulic lift
Features:

Driven by double hydraulic cylinders, chain-type elevating system

The stabilization system of steel wire rope, it ascends and descends smoothly

Multi-voltage power supply is available for convenient use

Two sides manual safety lock release system

Asymmetric design, make the auto door can be opened with narrow width between pillars

Economical but reliable cast-iron cover motor, Optional aluminum motor

Optional imported pumping device

Technical data
Lifting capacity 7714lbs/3500kg
Lifting height 71"/1800mm
Lifting time 50seconds
Overall height 111"/2816mm
Overall width 138"/3500mm
Width between columns 110"/2800mm
Motor voltage 220V or 380V
Frequency 50Hz or 60Hz
Phase 1ph or 3ph
Net weight 1417lbs/643kg
