CE Approved 0.01~0.02 (mm) Gooda Manufacturer Steel Box Wire Cut EDM Machine

Product Description

Product descriptions:
1. Spindle head The spindle adopts Taiwan Province famous brand Taiwan Province Pusen. Enlarged shaft diameter, good rigidity, large torque, good motion stability and high precision. 2. Guide rail of machine tool The guide rail is designed with rigid sliding guide rail, which has good rigidity and stability of heavy cutting (heavy roller linear guide rail can also be used for X axis). 3. Cross ram
The ram adopts super-large contact surface and reasonable rib arrangement to ensure the bending and torsional rigidity of ram, which is suitable for heavy cutting. Y-axis and Z-axis are equipped with a new type of hydraulic locking device, which ensures the stability of the machine tool during heavy cutting.
4. Feed transmission system
Three-axis drive adopts large-diameter grinding double-nut ball screw made in Taiwan Province, with compact structure, stable movement and high precision.
5. Lubrication system
X axis adopts forced circulation lubrication system. Other quantitative centralized lubrication systems are used to realize regular quantitative thin oil automatic lubrication for important parts such as guide screw through PLC program control. Ensure timely, accurate, reliable and pollution-free lubrication.
6. Automatic chip removal
Chip remover is installed in the middle of workbench and column, and adopts spiral or shaking chip removal.
7. Machining tool cooling
The tool is cooled by air. The air supply pipe passes through the ram above the beam to the cutting tool and cools it. Cutting fluid can also be used to cool the tool (special accessories).
Specification:

Item		Unit	Model
			TH-600NC
Cutting Capacity	Control Axis	No.	4
	Max.Milling Size (L*W*H)	mm	600*600*240
	Min.Milling Size (L*W*H)	mm	30*30*10
	One time Cutting Capacity	mm	2*2.0
Travel	X axis	mm	305
	Y axis	mm	305
	Z axis	mm	790
Feed Speed	X/Y/Z Max. rapid feed rate	m/min	9
	Max.Cutting feed rate	m/min	9
	Manual feed speed	mm/min	1-1500
Spindle	Spindle speed	Rpm	50-500
	Spindle taper	-	NT50
	Cutter diameter	mm	250
Motor	Spindle servo motor	Kw	2*11 OP 15
	X/Y axis feed servo motor	Kw	1.8
	Z axis feed servo motor	Kw	1.8
	Rotary table Servo motor	Kw	1.8
	Clamper hydraulic motor	Kw	1.5
Work table	Worktable dimension	mm	400*400
	Max.Loading weight	Kg	800
Hydraulic Clamper	Cylinder No.	Pcs	1 OP 3
	Oil tank volume	L	60
Lubrication system	Lubricating oil tank	L	4
	Lubricating power	W	18
Floor space require (L*W*H)		mm	3.8*4.0*2.3
Machine weight		ton	9
CNC system			FANUC or Mitsubishi or Siemens

GOOD EQUIPMENTS,MADE BY GOODA.

---
