Waterproof IP65 Hydraulic Valve Proportional Coil Joystick Wireless Remote Controller System

Product Description

Hydraulic Joystick Remote Control KitsGCJX-100: 4 JoysticksStrong penetrating power
Whether it's powering on/off or action commands, it can quickly respond and enjoy the convenience of wireless control.Product Parameters

Model	GCJX-100	GCJX-200	GCJX-400	GCJX-700
Button	4 joysticks	2 cross joysticks & 2 joysticks	4 joysticks	7 joysticks
Protection level	IP65
Corrosion protection grade	WF2
Transmit power	≤10MW
Rated power of receiver	≤6MW
Response time	≤20MS
Channel spacing	25HZ
Moulation mode	GFSK
Signal transmission rate	9600BIT/S
Signal reception sensitivity	-115DBM
Function customization	Accepted
OEM/ODM	Accepted
Working humidity range	0~97%RH
Adaptive temperature	-40°C~+85°C
Button life	12 million times
Shell material	PA66+ high quality fiber
Transmitter supply voltage	DC 1.8-3.6V
Receiver supply voltage	AC/DC 12V/24V/Customizable
Transmitting frequency	315MHZ/433MHZ/customizable
Remote control distance	225 Meters/Can be customized to 5km

Product Description Industrial wireless remote control system
1. Waterproof 2. Dustproof 3. Anti-rolling 4. Anti-drop
Quality Guarantee
Factory direct sale , Support for customHydraulic Remote Control
1. With 25 function buttons.2. Control points reach 25.3. Automatically cut off the circuit when the power supply voltage is insufficient.4. Key functions can be set according to needs.Hydraulic Valve with Joystick Remote Control
1. Intelligent wireless technology. 2. Signal is not afraid of interference.
3. Low and stable signal transmission power.
4. Remote control distance can reach up to 250 meters in open environments.The signal is stable and can operate normally in complex construction environments.The signal has strong penetrating power.The remote control distance is long.The transmission distance can be customized according to actual needs.
Our Advantages1. Designed with a battery voltage warning device, it automatically shuts off the circuit when the voltage is insufficient.
2. Adopting intelligent wireless technology to design circuits, with strong penetration and signal fearless interference.
3. The remote control casing is made of PA66 and high-quality fiber, which is one-time die-cast, comfortable to touch,and resistant to falling and pressure.
4. The remote control relay adopts the American brand TE, which is a leader in the relay field, with over 14000 global technology patents and decades of experience in relay development and production, ensuring excellent product quality.
5. The main chip of the remote control adopts Texas Instruments (TI) and South Korean ABOV brands, providing customers with high energy efficiency, ultra stable, and ultra safe semi conductor solutions and product services. It adopts a low-power design method and can be used normally for up to one month.
6. The remote control button adopts the world-renowned Alpine brand, with a unique structure, optimized materials, advanced technology, comfortable touch, and long service life. The embedded parts, base parts, spring parts, button parts, and cover parts of the button all use the best materials and processing technology to ensure the overall quality of the button, ensuring a service life of 12 million times, sensitive contacts, and quick response.
7. The remote control transistor adopts the Japanese brands of RENESAS and ROHM. As a leading manufacturer of microcontrollers and analog power devices worldwide, RENESAS and ROHM have taken the forefront in product solutions and system solutions.
Customisable Sections1. L0G0 CustomizationLOG0 styles can be designed and formulated according to customer needs.2. Button CustomizationButton icons are available in a variety of styles for customers to choose from and can be customized as needed.3. Function CustomizationThe number of buttons, single and double speeds, and some functional requirements can be customized.4.Control Distance CustomizationThe standard control distance of the product is 225 meters in open areas. Longer remote control distances can be customized according to needs.5. Linkage CustomizationOne transmitter can be customized tocontrol multiple receivers according to customer needs, or multiple transmitters can control one receiver.Detailed Photos Applications Scenarios
Aplication of Industrial Remote Control lt can be used in most fields. At present, the ECD remote control system is mainly used in eight fields: lifting machinery, construction machinery, port machinery, engineering machinery, industrial customization, agricultural and forestry machinery, computer numerical control machine tools, explosion-proof machinery, and special vehicles, such as cranes, engineering machinery, lifting platforms.travelling vehicles, hydraulic equipment, automobile tailboards,breakdown trucks, conveyor belts, industrial equipment androbots.I'm Born to Be Useful With the industrial remote control system, workers can hold the portable transmitters on hand, walk freely and choose the best position to operate. lt makes the working environment be safer, reduces the injury accidents and saves manpower cost during the operation. With remote control, the operator can finish various tasks independently, which will improve the working efficiency.Packaging & Shipping
Company Profile
HENAN NOMI ELECTRONIC TECHNOLOGY CO., LTD, is located in Zhengzhou Airport Intelligent Manufacturing Industrial Park, Henan Province. It is a technology development enterprise integrating R&D, design, manufacturing, operationand sales. Nomi Electronics has long been focusing on the R&D and practice in the field of industrial wireless remote control. After years of development, it has become aleading enterprise in the field of industrial remote control, which integrates independent research and development, technical consultation and system integration, and integrates remote control and intelligence of equipment.
The company continues to deepen the field of wireless remote control, helping the industry to develop in asmarter, more efficient and safer direction Nomi Electronics regards "creating brilliance, only quality" as its business principle.and "always providing safe and reliable industrial wireless remote control products" asits enterprise mission. Committed to developing safe, reliable, durable, andhigh-quality industrial wireless remote control equipment, improving work efficiency and providing operators with a more convenient and safer operating environment. Inindustry, construction, forestry, mining, etc. The field realizes the perfect unification ofmechanical equipment and intelligent control.
1.QUALITY
Good material makes a good quality, we have been guided by the principle of quality first.
2. ODM & OEM We support ODM /OEMservice, can better satisfy thecustomers.
3. SERVICE
We meet all the needs of customers, customer-oriented, for customers to solve practical problems.
Certifications & Exipition
FAQ
1.What is your minimum order and payment method? We can accept sample orders for trial orders. T/T 100% for less than USD 10,000, and T/T 50% can be used for more than 10,000 US dollars.2. Will you provide after-sales service?
Of course
1) all products are subject to strict factory quality inspection before packaging.2) all the products are packed in our factory, and the second package is delivered byexpress delivery before shipment.3) if there are any problems during operation or installation, please contact us freelyand we will solve them with professional guidance.3. ls there a warranty?
Of course. All our branded products have a 12-month warranty period. We provide24-hour after-sales service and technical support. If you find any problems during installation, please feel free to contact us.4. What certificates are approved for your product?
We have CE, FCC, RoHS, ISO9001 and so on.5. Can you customize it according to my needs?You can send me inquiries according to your needs. we can customize them with technical engineers.6. ls your price the lowest?
Do you mind the quality? The quality of our supply is value for money, inferior products will waste and affect the work process, why not choose a medium price to work well?7. ls the product 100% assembled?Yes, all the products are 100% assembled.

---
