Variable Spindle Speed Desktop Drilling Milling Machine Zay7045V Milling Drilling Machine

Product Description

Products Description:
Variable Spindle Speed Desktop Drilling Milling Machine Zay7045V Milling Drilling Machine
Performence Features:
Variable speed
Milling, drilling, boring, reaming and tapping
Head swivels 90 vertical
Micro feed precision
Adjustable gibs on table precision.
Strong rigidity, powerful cutting and precisely positioning.
Technical parameter:

ITEM	ZAY7045V
Drilling capacity	45mm
Max Face mill capacity	80mm
Max End mill capacity	32mm
Distance from spindle nose to table	400mm
Min.distance from spindle axis to column	285mm
Spindle travel	130mm
Spindle taper	M.T.4 or R8
Range of spindle speed(2 steps)	100-530,530-2800r.p.m,
Swivel angle of headstock(perpendicular)	±90°
Table size	800×240mm
Y axis travel of table	175mm
X axis travel of table	500mm
Motor power(DC)	1.5KW
Voltage/Frequency	110V or 220V
Net weight/Gross weight	310kg/360kg
Packing size	770x880x1160mm

Standard Accessories:
Tie rob
Wedge
Allen wrenches
Double-end wrench
Drill chuck and arbor
Tool box with tools
Optional Parts:
Stand
Power feed attachment
Machine vice
Drill chuck
Milling cutter holder
Reducing sleeve
Mill chuck kits
Boring rod
Tapping electrical system
Coolant system
