IR and Hotair Oven (JB-800ZB)

Product Description

JB Series Medium wave dryer can match with Full automatic screen press as a complete production line. Can drying various inks fast. Widely used in paper cigarette package wine package label plate advertising plastic printed circuited boards and other printing industry. Multi-section combination design, according to the printing material and ink the combination. The standard configuration is of two Section of Medium Wave Near Infrared(IR), one section of cold air cooling, customer can increase or decrease.
Technical Parameter

Model		JB-800ZB	JB-1100ZB
Speed		3m/min-40m/min	3m/min-40m/min
Conveyor motor power		750w	750w
Feed sucking fan		0.75 kw	0.75kw
Medium wave heating section	IR lamp	1.2Kw×9pc(each section)	1.5kw x12pc (first section) 1.5kw x9pcx2 (other section)
	Hot air circle fan	0.75 kw (each section)	0.75kw(each section)x3
	Exhaust fan	0.37 Kw	0.37kw (each section)x3
Cooling Section	Cooling fan	0.55 Kw	0.55kw(each section)x3
	Cooling exhaust	0.75 Kw	0.75kw(each section) x3
Weight		About 8500 Kg	About 9500kg
Overall		10.61 ×1.49×1.49 m	10.61x1.79x1.49m

---
