5 % off on Discount Bucket Capacity 0.21cbm Maximum Digging Depth 3820mm Mini Construction Machine Hydraulic Crawler /Track Digger Excavator

Product Description

5 % off on Discount Bucket Capacity 0.21cbm Maximum Digging Depth 3820mm Mini Construction Machine Hydraulic Crawler /Track Digger Excavator
.
Product features
Exclusive highly efficient hydraulic control system Main pump: Kawasaki or Rexroth, optional
Control valve: Doosan
Effectively prevent mixing of soil and rock
Highly efficient and rapid operations
High-strength frame structure and greater ground clearance

Easy to use
The operating system of the Small Excavator is much easier than the old one. Almost every ordinary person can operate this type of machinery and gets the benefits like as a skilled person. Its operating system is very easy and trainee-friendly that reduces training costs and time. Easily face the Nooks and crannies
Micro and compact excavators and diggers can easily exercise into small places compared to full-size equipment. The easy availability and accessibility of this small type of machinery made it more beneficial for the people. Low Noise
Mini Excavator made less noise during crossing the cemented and hard areas. This advantage made them more useful for residential areas. Easily transported
The biggest concern of hiring equipment is the transportation from one place to another. The transport of heavy machinery takes more cost, time, and space due to its extra energy consumption and is also harder to move. Save money
Operators of Mini Excavators have not needed any special commercial driving training for operating and moving. Micro excavators and small diggers played extraordinarily beneficial and versatile and proved the best choice for your current projects.
Its small size and economical choice have them a significant advantage for their users. Mini Excavators deliver the same job and performance as large excavators and save money .
Product Parameters

Performance parameters
Weight	5.95T
Bucket capacity	0.21m3
Engine rated power	35.5KW
Swing speed	9.5min-1
Travel speed (high/low)	4.1/3.0km/h
Ground specific pressure	32 kg/cm2
Gradeability (%)	70
Digging force	37.7KN
Boom length	3000mm
Arm length	1600mm
Working range Maximum digging depth 3820mm Maximum digging height 5760mm Maximum unloading height 4030mm Maximum digging radius 6155mm Minimum turning radiusc 2205mm	Advantage 1. Exclusive highly efficient hydraulic control system 2. Powerful travel traction3. Effectively prevent mixing of soil and rock4. Highly efficient and rapid operations5. High-strength frame structure and greater ground clearance6. Safe and open engine hood7. Convenient and swift maintenance
Dimensions
Transport length	5855mm
Transport arm height	2580mm
Tumblers distance	1960mm
Radius of gyration platform end	1690mm
Counter weight ground clearance	720mm
Track gauge	3303/2743mm
Total width of undercarriage	1885mm
Width of upper structure	1790mm
Width of track shoe	400mm
Ground clearance	360mm
Total length of travel mechanism	3750mm
Cabin height	832mm

Detailed Photos



application

landscaping
Mni excavator can perfectly replace manpower in landscaping construction
indoor decoration
Mni excavator small size ensures that it can access into inner building space to carry out constructions jobs .
Company Profile
JINAN FORTIUS INTERNATIONAL TRADING CO.,LTD which is located in the capital city of Shandong Province-Jinan,is a group company established by few 10-years working experienced experts for SINOTRUK trucks, trailers and spare parts. construction machine , new energy vehicles .We have dealt with many projects in China and abroad, such as TANZANIA STRATEGIC CITIES PROJECT, Uganda CITIES Sewage engineering, Guinea city electric project, Brunei Port project, Fiji logging transportation, Philippines mining project and so on.We have "heavy duty fans" from all over the world now, hope you may joint us, and let start a good and pleasant business


Detailed products
Packaging & Shipping
Confirm ordering quantity so that we use wooden box or load into container. Make it clear how the quantity each container could load according to size of each model Decide how to transport according to our trade terms With the detailed address, deliver through custom to the right place

FAQ
Q1. What is the delivery period? After receiving the initial payment, the goods will be ready for delivery within 5 days. The rest time depends on the distance and transport method which need to be negotiated. Q2. What is the payment terms can you accept? 30% initial payment, 70% balance payment when the goods are ready for delivery by T/T.Q3. How long is the product guarantee or warranty? We provide 18 months quality guarantee, and lifelong technical support.Q4. What kind of service could you provide? 1) Pre-sale service: we could assist you finding the suitable equipment according to your requirement. 2) On-sale service: we strictly follow the commercial rules, contract signing, following the production process, controlling the goods quality, tracking the goods delivery, guaranteeing you receive the qualified goods safely. 3)After-sale service: we provide some consumables with the equipment; We have operation manual for instructing the basic installation and operation; video guidance for trouble shooting; engineers ready for field maintenance and repairing when necessary.Q5. Can we have the special order like specification change, logo making?Yes, we accept the customization. We can make it clear in the contract and then our technical start design and production as per your requirement.

---
