10~24m Diesel Electric Hydraulic Towable Boom Lift

US$6,999.00-8,999.00 1 Piece (MOQ)

Basic Info.

Model NO.
TBL
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Hydraulic
Carrying Capacity
200 Kg
Moves
Towable
Driven Type
Hydraulic
Running Mode
Moving
Feature
Explosion-Proof, Insulating
Certification
GS, CE, RoHS, ISO 9001
Power Available
AC/DC/Diesel/Gasoline/AC+DC, etc
Color
Yellow, Red, Green, or Per Your Request
Maximum Platform Height
10m, 12m, 14m, 16m
Maximum Working Height
12m, 14m, 16m, 18m
Voltage
220V/110V/230V or Per Your Request
Type
Telescopic
Transport Package
Full Container
Specification
5500*2200*2200
Trademark
PLK
Origin
China
HS Code
8428909090
Production Capacity
500 Per Month

Product Description

Articulated Hydraulic Aerial Platform Telescopic Towable Boom Lift For Sale
Towable boom lift platform height from 10m to 16m (working height from 12m to 18m). Load capacity 200kg. It can be towed easily from site to site and work for you quickly. It is widely used for aerial working, such as road lamp repair, palm tree trimming work and cleaning the window etc.
Power options available on PLK towable boom lift include AC (connect with electricity), DC (battery power), gasoline, diesel and 'Dual-Energy' ( for example battery & diesel or battery & gasoline), combining the benefits of two power sources on the same machine. Towable Cherry Picker is popular for its easily moving and operation. Having it will be your wisest choice.
Model TBL-12A TBL-14A TBL-14AT TBL-16A TBL-18A TBL-20A TBL-22A TBL-24A
+Telescopic +Telescopic +Telescopic +Telescopic +Telescopic +Telescopic
Lifting height 10M 12M 12M 14M 16M 18M 20M 22M
Working height 12M 14M 14M 16M 18M 20M 22M 24M
Load capacity 300KG 220KG 300KG 300KG 220KG 220KG 220KG 220KG
Platfor msize 1.2*0.8M
Working radius 5.5M 6.5M 7.8M 8.5M 10.5M 11M 11M 11M
Net Weight 1950KG 2100KG 2150KG 2150KG 2350KG 3800KG 4500KG 5000KG
Overall Width (A) 1.7M 1.7M 1.7M 1.7M 1.7M 1.8M 1.8M 1.9M
Stowed Height (B) 2.1M 2.1M 2.1M 2.1M 2.2M 2.25M 2.25M 2.25M
Overall Length (C) 6.3M 7.3M 5.8M 6.65M 6.8M 7.6M 6.9M 6.9M
Length After Folding Tractor (D) 5.2M 6.2M 4.7M 5.55M 5.7M 6.5M 5.8M 5.8M
Wind Resistance Level <=5
Rotation 359 degree (USD350 for 360d egree) 360 degree
20'/40'Container Loading Quantity 1set/3sets 1set/3sets 1set/3sets 1set/3sets 1set/3sets 1set/2sets 1set/2sets 1set/2sets
