300L 500L 1000L 1500L 2000L Small Brewery Equipment Microbrewery for Beer Brewing System

Product Description

Product Description
300L 500L 1000L 1500L 2000L Small Brewery Equipment Microbrewery for Beer Brewing System
> Brewhouse Combination Diversification----Customized
> Decoction,infusion,multi-step infusion mashing can be realized.
> Electric,Steam,Gas directly fire heating source for optional
> 15-20 days free installation and training service offered by profession engineer.
> Mirror polishing and wire drawing SUS 304 for optional,thickness:3-4mm
> Rational layout, Humanized design and convenient operation

2 Vessels Brewhouse System	3 Vessels Brewhouse System
Combination Mash/Lauter tun+Brew kettle/whirlpool tank Capacities: 100L-3000L, 3/5/7/10/15/20/30BBL Heating Sources: steam, electric, direct fire	Combination 1.Mash/lauter tun + brew kettle + whirlpool tank 2.Mash tun +lauter tank + brewkettle & whirlpool tank Capacities: 100L-5000L, 3/5/7/10/15/20/30BBL Heating Sources: steam, electric, direct fire
Combinated 3 Vessels Brewhouse System	4 Vessels Brewhouse System
Combination 1.Lauter & storage tank+brew kettle/whirlpool tank 2.lauter& whirlpool tank+brew kettle +whirlpool tank 3.Lauter & HLT+brew kettle +whirlpool tank Capacities: 100L-1000L, 3/5/7/10BBL Heating Sources: steam, electricm directly	Combination: Mash tun, lauter tank, brew kettle, whole tank Capaticity:2000-5000L, 20/30BBL Heating Sources: steam

Configuration of 500L Craft Beer Equipment
UNit	Components	Capacity	Specification
Milling	Miller	200KG/H	Double Roller,Noise<60db
Brewhouse	Mash/Lauter tun	500L	Mashing Process:Decoction.Infusion.Multi-step infusion
	Brew Kettle/Whirlpool Tank	500L	Heating source:Steam,Electric,direct fire SUS304/Red copper
	Hot Water Tank	800L	Heating source:Steam,Electric,Gas
	Heat exchanger	5 SQM	Stainless steel plate
Fermentation tank	Fermentation Tank (The number according to customer requirements)	500L or 1000L	Top manway/Side manway Drying hop port to brew IPA Dimple Plate Cooling jacket Carbonation port to fill CO2
	Yeast Adding Tank	5-10 L	SUS304 Stainless Steel
Cooling System	Glycol Water tank	1500L	Equiped with PU level indicator
	Chiller	5Hp	UL/CE certified electric elements,Copeland compressor
	Pump	3T/H
Cleaning System	Disinfection Tank	50-100L	SUS304 full welded
	Alkali Tank	50-100L
	Pump	3T/H
Control System	Control Cabinet	PID or PLC
Optional	Auger System Grain Case Grist Hydrator Piping flow panel for Brewhouse Brewhouse Separate PLC Controller Steam Boiler Customized ...

Our Advantages
Company Profile

Customer case
Customer Feedback
Packaging Details
1.LCL/FCL(20GP/40GP/40HQ)
2.Packed with plastic film in fumigation free wooden case or fixed with iron frame
3.Up to export standard, suitable for delivery
4.Customer's requirements available
FAQ

1. What Certificate do you have for your beer brewing equipment?
We can offer CE, PED, UL certificate.
2. Mashing system can be controlled automatically?
Yes. You can input your recipe into the control cabinet, then it can be finished automatically.
3. Your brewery equipment has hops back?
Yes, we install hops back for all our brewery equipment.
4. What is pressure of fermentation tank?
0.15Mpa for fermentation, 0.3Mpa at most---------
5. What is delivery time?
40 working days.
6. Can I visit your factory?
Yes, you are warmly welcome to visit us at any time. We will treat you with our beer.

---
