Infrared Object Detection Sensor for Smart Electronic Parcel Delivery Locker System

Product Description

Infrared Object Detection Sensor offers simple, user friendly and fast object detection using IR for smart electronic lockers. It is non-contact detection. The implementations of modulated IR signal immune the sensor to the interferences caused by the normal light of a light bulb or the sun light. The module will output a HIGH IF NO object is detected and a LOW if an object is detected. Infrared sensor uses special sensor to modulate IR signal emitted from 2 IR transmitters and detects the modulated IR signal reflected back from a nearby object.
Features Transmitter and receiver built in one
Length can be extendable for multi sensors
LED light for illumination
Low current consumption Small LED as indicator for detection status Detection range: 0-40CM The sensing range will not be affected by the surface color of obstacle. Compact size for hidden installation. Compatible with all types of locker access controllers
Specification

Operation Voltage	8-24VDC
Operation Current	Less than 20mA
Working Temperature	-10C ~ +80C
Working Humidity	10%-90%R.H
Atmospheric pressure	86kpa-106kpa
Dimensions LxWxH	335.7mm*17.1mm*10mm
Gross Weight	0.3kg

About US
Dajiang is a designer and manufacturer specializing electrified locking solutions for lockers, cabinets and kiosks. No matter size-restricted enclosures or heavy-doored metal cabinets; we can meet your particular security requirement with customized design for your applications.
Our ranges cover electronic cabinet locks, electronic drawer locks, smart parcel locker control system, vending machine control system, and IOT control hardware and software. With professional security control solution, Dajiang locks and controllers is ideal for areas of parcel locker, smart lockers, vending lockers, cash drawers; post mailboxes; medicine and archive cabinets; Key Cabinets and mailbox.
Quality control melts into the whole process and our products are completed under continuous supervise and multistage of tests. We are very proud of our product and service. We are confident you will enjoy the experience with us and appreciate all opportunity to answer any questions or provide any further information.

---
