High Quality Three -Row Multiple Drilling Machine

Product Description

MZB63A Single-Row Multiple Drilling Machine
Model NO.: MZB63A Precision: High Precision
Certification: CE, ISO 9001 Condition: New
Maximum Diamenter of Holes: 35mm Depth of Drilled Holes: 0-60mm
The Number of Spindles: 63 Center Distance Between Spindles: 32mm
Rotation of Spindle: 2840r/Min Specification: 2.4CBM
Total Motor Power: 3kw Suitable Voltage: 380V
Air Pressure: 0.6-0.8MPa Overall Size:2400*1200*1500mm
Trademark: QDZD Transport Package: Wooden Case
Specification: 2.4CBM Origin: Qingdao
HS Code: 84659500
Technical Data:

35 mm	Max. diameter of holes
0-60 mm	Depth of drilled holes
63	The number of spindles
32 mm	Center distance between spindles
2840 r/min	Rotation of spindle
4.5 kw	Total motor size
380 v	Suitable voltage
0.5-0.8 Mpa	Air pressure
20L/min Approximately	Gas consumption for drilling ten panels per minutes approximately
1850 mm	Max. distance of the two longitudinal heads
800 mm	Height of working platform off the ground
2600x2600x1600 mm	Over size
2700x1350x1650 mm	Packing size
1260 kg	Weight

Other information:
1) Term of payment: T/T, 30% deposit and the balance is paid before delivery
2) Delivery: 25days
3) Machine voltage: optional
4) Warranty: 1 year
5) MOQ: 1 Set
6) OEM service is ok
7) HS code: 84659500
8) Certificate: CE&ISO 9000 Certificate
Qingdao Zhongding Machinery Co., Ltd is a leading company of specializing in manufacturing and exporting woodworking machine, and we are able to offer professional woodworking machines to customers. Our company has professional technology, full range of testing lines and pipelining, and four professional production lines of woodworking machine. It is located by the beachside of the Yellow sea, which is a place of strong competitive power, beautiful natural environment, and easy traffic of air, land and sea transportation.
Our products mainly include Precise Panel Saw, Edge Banding Machine, Multiple Drilling Machine, Press Machine etc., which have been exported to lots of countries and regions, such as Europe, Russia, Southeast Asia, Middle East, North America, and Australia.
We have established complete sales system. Our company takes the principle of quality first and customer foremost and we are strict with quality control. Meanwhile, we develop and manufacture new products positively, and provide perfect pre-sale and after-sale services. At the same time, our company has got ISO9001 international system certificate and CE security certificate.
Qingdao Zhongding Machinery is looking forward to establish long-term strategic cooperation relationship with you and offer you high quality products and perfect service system.
