| 0perating weight | 9200KG |
| Transportdimension | 6230X2365X3752mm |
| Wheel base | 2250mm |
| Min.Ground clearance | 300mm |
| Turning radius | 3500mm |
| Bucket capacity | 1.0m3 |
| Breakout force | 38KN |
| Loadinglifting capacity | 2500KG |
| Dumping height | 2650mm |
| Dumping reach | 1025mm |
| Loading cutting depth | 52mm |
| Max.Diggingdepth | 4085mm |
| Max.Tractive force | 39KN |
| Rated power | 75KW/100HP |
| Rated speed | 2400r/min |
| Gears | 2 Forward and 2 reverse gears |
| Bucket digging force | 46.5KN |
| Cooling mode | Oil-cooling pressure circulation |
| Travel speed | 28Km/h |
| Steering angle | 36° |
