| Model | JDA4-600 | JDA4-800 | JDA4-1000 | JDA4-1300 |
| Width of Material (mm) | 70-600 | 70-800 | 70-1000 | 70-1300 |
| Thickness of Material (mm) | 0.6-6.0mm | |||
| Max. Coil Weight (Kg) | 5000 | 5000 | 7000 | 10000 |
| Coil I.D.(mm) | 508 | 508 | 508 | 508 |
| Coil O.D.(mm) | 1400 | 1400 | 1400 | 1400 |
| Max. Speed (m/min) | 16~24m/Min | 16~24m/Min | 16~24m/Min | 16~24m/Min |
| Feed Accuracy | ±0.1/100mm | |||
| Maximum feeding length(mm) | ~500 | |||
| Work Rollers（Pcs） | Up 6/ Down 5 | |||
| Feed Line Height | Accoring to customers’ Requirements | |||
| Power Supply | 220V&380V | |||
| Uncoil Expansion | Hydraulic Expansion | |||
| Air pressure（Mpa） | 0.49 | 0.49 | 0.49 | 0.49 |
| Uncoil Motor (Kw) | 2.2 | 2.2 | 3.7 | 7.5 |
| control system | PLC+touch Screen | |||
| Material:Medium and high strength steel plate | ||||
| Material Thickness：1.0～6.0 mm Note: Please refer to the correction ability table for thickness x width | ||||
| Material Width：100 ～ 1800 mm | ||||
| Yield Strength ：≤1370 N/mm2 | ||||
| Coil Inner Diameter:Φ450~φ530mm/φ480~φ530mm/φ580~φ630mm | ||||
| Coil Outside Diameter:max φ 1600 mm | ||||
| Coil Weight:3000~15000kg | ||||
| Standard Configuration: Photoelectric arc control system Feed outlet guide rack device Press arm device The feeding line height is adjusted by screw worm gear Dial indicator Arc control roller The rack contains air pressure disc brake device Rack variable frequency speed regulation Optional Configuration Feed line height electric adjustment device Hydraulic automatic loading trolley | ||||
