US$1,944.00-11,944.00
|
1 Piece
(MOQ)
|
Basic Info.
Max Power Consumption
6500W
Length of Fiber Cable
10 Meters
Lase Beam Width
100 X 100mm (Option)
Max Scanning Speed
30, 000mm/S
Operation Language
Multiple
Cooling Way
Water Cooling
Power Supply
1 Phase / 220V / 50-60Hz
Emergency Button on Cleaning Head
Yes
Transport Package
Plywood
Specification
1240 x 780 x 1258 mm
Product Description
JEZ 1500W laser rust remover with high power laser which mainly for rust removal and paint stripping .
The laser cleaner using field lens mode, the laser output is more stable and higher efficiency .
Specifications (For Reference):
| Laser Power | 1500W |
| Power Supply | 1PH / 220V±10% / 50-60HZ |
| Cooling Way | Water cooling |
| Power consumption | 6500W |
| Length of fiber cable | 10 meters |
| Laser Beam Width | 150-500mm(Option) |
| Laser Beam types | 4 different types |
| Cleaning Head | 2D handheld Clean Head |
| Weight Of Cleaning Head | 1.5 KG |
| Cleaning Head Emergency button | Yes |
| Max Scanning speed | 30,000mm/s |
| Air Blow function to protect Focus lens | Yes |
| Air Blow function to improve working efficiency | Yes |
| Scanning Mode | F-Theta |
| F-Theta Option | F254 / F300 F420 / F500 |
| Size Of Machine(mm) | 1240 x 780 x 1258 |
| Net Weight Of Machine | 248KG |
Product feature :
1. Support high power laser (Max 3000W) for long time stable working
2. Simple operation and efficient multiple laser cleaning patterns
3. Multiple safety operation locks ,can store multiple sets of working parameters
4. 3-colors work light self-test function
5. Hand-held cleaning head emergency stop button to cut off laser output in time if any emegency situation
6. Each core component of the machine (laser, water tank, control card, etc.) has a separate circuit protection
7. Alarm feedback of core components (water tank, laser, cleaning head, etc.) to the screen
8. Most of the circuit components are imported brands, which are more durable and stable
9. High speed cleaning speed ,max can be 30,000mm /
10. No need for chemicals and other media, green and environmentally friendly cleaning method
Applications:
1. Thick Rust ,Paint ,coating removal
2. Paint removal from Marine and shipyard
3. Restoration and maintenance of heavy machinery
4. Oil field equipment cleaning and maintenance
>>
