500kg/Hr PP PE Woven Bag LDPE LLDPE Film Hot Washer Crushing Washing Drying Line Plastic Recycling Machine

Product Description

500kg/Hr PP PE Woven Bag LDPE LLDPE Film Hot Washer Crushing Washing Drying Line Plastic Recycling Machine
Product Description
Plastic PP PE film washing recycling line adapt to wash various type of film and woven bags which impurity content reach to 80%. The waste dirty material go through crushing, friction washing, washing, dewatering, hot air drying process will turn to be clean flakes for pelletizer.
Working principle of plastic film cleaning line:
Plastic shredder/crusher: The first step in the plastic cleaning granulation line is to use the plastic shredder to cut the plastic film into small pieces. The resulting plastic parts plastic shredder size is about 30mm-100mm.
Plastic rinsing tank: Plastic rinsing tank plays a key role. The plastic washing machine can remove the dirt, grease, dust, residue and other impurities on the plastic surface through a series of water washing, so that the plastic debris is treated more clean and pure. Clean plastic materials can result in higher quality recycled products and reduce wear and damage to pelletizer and other recycling machines.
Centrifugal dehydrator/squeezer: A vertical centrifugal dehydrator is a commonly used solid-liquid separation device whose main purpose is to dehydrate the plastic suspended in the liquid to the desired humidity or degree of dryness. The centrifugal dehydrator separates liquids and solids by centrifugal force, enabling an efficient dehydration process.
Product Silos: Silos are used to store clean and dry plastic film sheets.
Plastic granulator: Plastic granulator is one of the important recycling machinery in the plastic film cleaning line, and its main use is to heat and melt the recycled waste plastic, and then the plastic melt is extruded through the mold. Recycled plastic pellets can be used as an alternative raw material for the manufacture of various plastic products, thereby reducing the demand for virgin plastics and reducing production costs.
Particle granules packaging machine: The packaging machine is used to pack plastic particles into bags.
Features
Plastic Film Washing Recycling Machine Features:
1. The high-speed centrifugal cleaning system applies the corresponding blade impact force to different materials at suitable rotating speed to achieve the cleaning effect.
2. The dehydrator, squeeze dryer and hot air echoing to strictly control the moisture content of the finished product within 5%, which is suitable for high-quality granulation requirements.
3. The plastic film washing recycling line can be displayed "L" or "U" shape according to clients' workshop.
4. RETECH Machinery can also customize the plastic film washing line components according to customer's material and product requirement.
Detailed Photos

Product Parameters

Capacity(kg/h)	Power(kw)	Area(m²)	Labor	Water(m³)
300	130	150	2	5
500	280	300	3	8
1000	425	500	4	10

Certifications
Packaging & Shipping
Exhibition

FAQ
Q&A about recycling machines:
1. What is the function of the PE PP film washing recycling machines?
The PE PP film washing recycling machinery is used to recycle and process the PE agriculture film, PE bags, shopping bags, beverage bags, PP woven bags, and some other soft material etc…
2. Where does it collect the waste material for the PE PP film washing recycling machines?
The waste mater is gotten mainly from agriculture film, city rubbish and plant in bale package or separated. They are with much dirties, such as the earth, soil, sand, stone, glue, grass, oil, and some other dirties.
But by our many years experience to manufacture the washing line, we can promise to wash the material clean enough to take the washed material into the extruder to make granules. We have our special design to guarantee this point.
3. What are main parts of the PE PP film washing recycling machines?
The following is a standard structure of the PE PP film washing recycling machinery:
Belt conveyer--- crusher with water--- screw conveyer--- floating washer--- screw conveyer--- high speed friction washer--- high speed friction washer--- screw conveyer--- horizontal centrifugal dewatering machine (or squeezer)--- drying system 1--- transition hopper--- drying system 2--- storage silo--- operating panel
The up is a standard structure of the line, we can adjust it to remove some parts or add some parts due to the situation of the material or customers' requirements.
4. What capacity of the PE PP film washing recycling machinery?
300-1000kg/h for single washing line
5. What power of the PE PP film washing recycling machines?
150kw~480kw
6. How much water does it need of the PE PP film washing recycling machines?
3~8T per hour
7. How large space does it need for a PE PP film washing recycling machines?
100~400 square meters, the whole line could be installed by straight, "L" shape or "U" shape. We could design how to instal the machines due to the space of your factory.
8. What is the condition of the final products from the PE PP film washing recycling machines?
The size of final flakes will be 50~100mm, and final moisture level of film flakes will be lower than 5%.
The PP PE flakes can be taken directly to the granulating/pelletizing line to make granules/pellets.
9. What is material of the PE PP film washing recycling machines?
The parts contacted with water are made of stainless steel SUS 304 or customized.
10. What certifications do you have for the PE PP film washing recycling machines?
We have CE and ISO9001 certification for the entire PE PP film washing recycling machines.

---
