High-Performance 4 Axis CNC Deep Hole Gun Drilling Machine for Metal

Product Description

Drilling stands as the fundamental cornerstone in machining operations, boasting a wide-ranging application field. Traditional drilling equipment like bench drills, milling machines, and radial drills have historically shackled laborers to repetitive tasks, often compromising quality. The constraints of security, efficiency, and processing limits have long affected manufacturers and operators. Enter the era of CNC technology-the revolutionary CNC deep hole drill has transformed this landscape. It emancipates the workforce, overcomes the bottleneck of deep drilling processes, and achieves the exceptional processing quality of traditional machines in drilling, enlarging, and expanding operations. Additionally, it automates chip removal, CNC positioning, and processing-ushering in a new age of precision and efficiency.

3 Axis CNC Deep Hole Drilling Machine	4 Axis Vertical CNC Deep Hole Drilling Machine	Multi-Spindle CNC Deep Hole Drilling Machine	6 Axis CNC Deep Hole Drilling Machine

4-Axis Vertical CNC Deep Hole Drilling Machine Introducing a groundbreaking vertical deep hole drill, featuring a specialized short gun drill ideal for small hole processing and tailored for batch injection pinhole operations. This innovation promises high precision, remarkable speed, and user-friendly operation while significantly reducing manpower requirements. Its versatility shines in fields like medical equipment, aerospace, hydraulic oil pumps, automotive spare parts, and beyond.
High-Performance 4 Axis CNC Deep Hole Gun Drilling Machine for Metal

Model	Unit	VMD-650
Inner diameter of drilling	mm	1.5-20
Max drilling depth	mm	220
Table size	mm	700*520
X/Y/Z axis travel	mm	600*500*300
Z2 axis travel	mm	300
Drilling cutting speed	m/min	1-300
Spindle taper		BT40
Max spindle rotary speed	rpm	10000
Spindle motor power	kw	7.5-11
X/Y/Z axis motor	kw	2.4/3.1/3.9
Z2 axis motor	kw	3.9
Load weight	kgs	500
Machine weight	kgs	4500
Machine dimension	mm	2800*2880*2600

Shenzhen Joint Machinery Co., Ltd. stands as a distinguished professional manufacturer and exporter of CNC lathe machines, CNC deep hole drilling machines, Swiss-type automatic lathes, milling machines, grinding machines, and more. Our unwavering commitment is to deliver top-tier machines and exceptional service to our global clientele. We focus on rigorous quality control and continuous improvement to ensure our machines surpass the highest industry standards. By integrating cutting-edge technologies from Taiwan and Germany with advanced production equipment and processes, we guarantee superior quality and reliability. Our machines are renowned for their precision, stability, and dependability, adept at handling complex and high-demand machining tasks. With a strong global presence, our products are exported worldwide, earning widespread recognition and popularity. Our market reach extends across Asia, Europe, South America, North America, and more. We pride ourselves on establishing enduring partnerships with customers worldwide, fostering mutual growth and creating substantial business value.

---
