Warp Knitting Spare Parts Karl Mayer Machine Bobbin Cast Beam

Product Description

Warp Knitting Spare Parts Karl Mayer Machine Bobbin Cast Beam

Specification: 30*21"
Internal bore: 160mm
Flange outer diameter: 762mm
Inside diameter: 296mm
Inner Length: 470mm
Weight: 64/65KGS
Beacuse of dynamic balancing function, a good compatibility with weaving machinery is maintained even through high-speed rotataion.
Through hard anodizing coating treatment, Corrosion and surface scratching are entirely prevented.
It retains durability and precision after working for several years.
Warranty period: Two years
We can also make the beam according to customer's drawing
If need more details, please feel free to contact us!
Technical Parameter

Model	10/25	10/25	8/35	6/45	6/55	4/65	4/80	4/55	4/80	2/165	2/200
No. of ribbon	10	8	8	6	6	4	4	4	4	2	2
Reed width	25	30	35	45	55	65	80	55	80	160	200
Direction of weft insertion			C.W.
Collocation of roller	Single roller		Single roller, Double roller collocation						Double roller		Double drum
Heald frame	16		Single roller: 16 Double roller: 16						16		12-6
Weft density	3.5-36.7/cm(8.9-93/inch)
Motor	1.5HP
Pick repeat	8-48

ONEREEL is specialized in the design and manufacture Steel Spools, Plastic Spools, Cable roller, Yarn Bobbin, aluminum spool , Cable Reel Stand, Sheave Pulley, Cable Conveyor, Hydraulic Puller Tensioner, Gin Poles, Cable Pulling Winch, Safety Tools, Wire Grip, Plastic Parts, and Pump in the industry since 1991. All of our customer spool and wire carrier are engineered and manufactured in our 120,000 square foot state-of-the-art manufacturing plant located in Ningbo, Zhejiang.
ONEREEL is specialized in the manufacture of reels for cables and electric wires, iron axles, disc spool for steel cables and various delivery reels. With strong technological capabilities and full series of production equipment. All of our products go through the dynamic and static balance tests. We have passed the quality system certification ISO9001:2000 to ensure the product quality. Following the standards of GB4004-83, JB/T8997, DIN46395 and DIN46397 in productions.
Hot Product
Our Customer


Packaging & Transportation

Authoritative Certificate


FAQ
Q1: Can I get samples?
A: According to spool model and material, we will advise.
Q2: How long is the sample LEAD TIME?
A: For existing samples, it takes 2-3 days. If no stock, we will advise lead time.
Q3: Can you develop new products?
A: Yes, we have new products developing ability and we are good at developing new mold.
Q4: How much is the freight charge?
A: It depends on spool package volume, if small quantity, volume and urgent goods,
we may advise FEDEX or other couriers' charge for your check.
If volume bigger and by seaway suitable, we provide FOB or CIF price to you.
Q5: What format of the file do you need if I want my own design?
A: We have our own mound workshop and can provide spool or other plastic product developing and injection service.
Q6: How about your service?A: We have pre-sale service, in-sale service and after-sale service. As "Customer First" is the most important principle of company operation.
You can freely help you out either Tech issue or Products requirements. Pls approach us. Thanks.

---
